Blue Sea Systems 2132 Push Button Reset Screw Terminal Circuit Breaker, 10A, 32V DC

• Branch circuit breakers (can also be used for 24-hour circuit protection)

• Quick connect terminal style circuit breakers are incorporated into Blue Sea Systems WeatherDeck Waterproof Circuit Breaker Panels, Dual Battery Bank Main Distribution Panels, and 360 Distribution Panels

• Compact design enables high density circuit protection configurations

• Push-to-reset operation

• "Trip Free" design cannot be held "ON" during fault current condition

• Ignition protected - Safe for installation aboard gasoline powered boats

• Optional Push Button Waterproof Boot protects circuit breaker in wet environments, replaces dress nut mounting on circuit breakers and resists discoloration and cracking

• Amperage: 10A

• Maximum Voltage: 32V DC

• Mounting: Panel Mount 3/8-27 UNS

• Circuit Breaker Type: Thermal trip, manual push-button reset only

• Terminal Type: #8 Screw

• Interrupt Capacity: 3000A @ 14.7V / 2500A @ 28V

• Minimum Operating Temperature: -10 C

• Maximum Operating Temperature: 60 C

• Screw Terminal Torque: 6 in-lb (0.68 Nm)

• Weight: 0.09lb (0.04 kg)

  WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The Blue Sea Systems 2132 push button reset screw terminal circuit breaker offers reliable 10-amp circuit protection designed for marine and other DC applications. Its thermal trip mechanism ensures safe operation by automatically disconnecting the circuit during fault conditions, while the push-to-reset feature allows for easy manual reset after a trip. This compact breaker is ideal for installation in high-density panel configurations, making it suitable for boat, RV, or industrial setups where space efficiency is crucial. The breaker’s screw terminals provide a secure connection, rated for #8 screws with a torque of 6 in-lb, ensuring stable and consistent contact.
Built with safety in mind, the 2132 is ignition protected, making it safe for installation aboard gasoline-powered boats. Its maximum voltage rating of 32V DC and interrupt capacity of 3000A at 14.7V ensure robust performance under demanding conditions. The breaker’s
