Description
3122 - SMS Panel Enclosure with ELCI (16A) 2 Branch (8A) - 230V AC
The 3122-panel enclosure is built for Equipment Leakage Circuit Interrupters (ELCI) main circuit breakers and other large frame devices. Meets ABYC E-11 when used with an ELCI Main circuit breaker and mounted within 10' of AC shore power inlet.
Features:
- Blank apertures for custom breaker loading
- Glass-filled polycarbonate base
- Clear cover allows easy view of circuit breaker status
- Overlapping cover for strength and increased gasket protection
- Oversized, formed in place seamless PUR gasket
- Easily removable stainless steel hinge pin for unobstructed installation
- Stainless steel latch secures cover without penetrating the enclosure
- Blank circuit positions accommodate Carling Technologies A and C Series Flat Rocker and ELCI Main circuit breakers
- Includes waterproof glands
- LED lights for backlighting and ON indication
Technical Specifications:
- Circuit Breaker Type - 1 x ELCI (16A) Main 230V and 2 x Branch (8A)
- Dimensions (Overall) (H x W x D) - 7.6" x 7.4"" x 4.7" (192 x 188 x 120mm)
- Dimensions (Enclosure) (H x W x D) - 6" x 6" x 4" (152 x 152 x 102mm)
- LEDs Installed - 1 x Red (Reverse Polarity - 230V AC and 3 x Green ON (230V AC)
In the Box:
- 3122 Enclosure
- Glands x 6
- Labels
- Mounting hardware
- Instruction manual
*Sold as an Individual
The Blue Sea Systems 3122 SMS Panel Enclosure is designed for mounting Equipment Leakage Circuit Interrupters (ELCI) main circuit breakers along with two branch circuit breakers, providing a reliable and organized electrical safety solution for marine and industrial applications. Constructed with a durable glass-filled polycarbonate base, this enclosure combines strength with corrosion resistance, ensuring long-term performance in demanding environments. The clear cover allows for quick and easy visual inspection of circuit breaker status, enhancing operational safety and convenience.
Features such as blank apertures provide flexibility for custom breaker configurations, while an overlapping cover design offers additional strength and gasket protection. The seamless PUR gasket, formed in place, ensures a watertight seal, protecting sensitive components from moisture and dust. An easily removable stainless steel hinge pin facilitates unobstructed installation and maintenance, and the stainless steel latch secures the cover without penetrating the enclosure, preserving its integrity. The enclosure includes waterproof glands for secure wiring connections, and integrated LED indicators provide clear visual status updates for the circuit breakers, with red LEDs signaling reverse polarity and green LEDs indicating ON status.
Measuring approximately 7.6 inches high by 7.4 inches wide by 4.7 inches deep, the overall enclosure offers ample space for installing the specified circuit breakers, compatible with Carling Technologies A and C Series Flat Rocker and ELCI main circuit breakers. The enclosure's compact design makes it suitable for various installation environments, especially where safety and durability are critical. Included in the package are six waterproof glands, labels, mounting hardware, and an instruction manual for straightforward setup. The Blue Sea 3122 enclosure is sold individually, providing a dependable solution for marine electrical systems and other industrial applications requiring a high-quality, compliant circuit protection enclosure.
Features:
- Blank apertures for custom breaker configurations
- Glass-filled polycarbonate base for durability and corrosion resistance
- Clear cover for easy circuit breaker status viewing
- Overlapping cover design enhances strength and gasket protection
- Formed-in-place seamless PUR gasket for watertight sealing
- Removable stainless steel hinge pin for easy installation
- Stainless steel latch secures cover without enclosure penetration
- Blank circuit positions accommodate Carling Technologies A and C Series Flat Rocker and ELCI Main circuit breakers
- Includes waterproof glands for secure wiring
- LED indicators for backlighting and ON status, including reverse polarity warning
