Description
4163 SS Push Button Switch - Off-(On) - Red - 10A
- 10A continuous
- Single Pole Double Throw or Single Pole Single Throw
- Can be wired for normally open or normally closed
- Installs with .110inch quick connects (included in retail package)
Specifications
- Action: OFF-(ON)
- Amperage: 10A @ 12V DC
- Nominal Voltage: 12V DC
- Maximum LED Operating Current: 20mA
- Minimum Operating Temperature: -10 C
- Maximum Operating Temperature: 70 C
- Minimum Storage Temperature: -55 C
- Maximum Storage Temperature: 85 C
- Illumination: Independent Separate contacts for LED power
- Mounting Hole: 19mm
- Switching Cycles: 18,000
- Termination: 5 0.110inch Quick Connect terminals
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
The Blue Sea Systems 4163 SS push button switch offers reliable performance for control panels and electronic projects. Designed with a vibrant red actuator, this switch provides a clear on/off indication and is rated for continuous 10A current at 12V DC. Its versatile wiring options allow it to be configured as normally open or normally closed, making it adaptable for various switching applications. The switch features separate contacts for LED illumination, enabling integrated indicator lighting that enhances visibility during operation. Installation is straightforward with included .110-inch quick connect terminals, and it mounts securely through a 19mm hole, ensuring a stable fit in panel assemblies. The switch is rated for approximately 18,000 switching cycles, suitable for demanding environments where durability is essential. Operating within a temperature range from -10°C to 70°C (14°F to 158°F), it performs reliably across diverse conditions, and its storage temperature range extends from -55°C to 85°C (-67°F to 185°F). With a compact form factor and robust construction, the Blue Sea 4163 SS switch is an ideal choice for marine, automotive, or industrial control systems requiring a durable and visually distinctive toggle switch.
Features:
- Rated for 10A continuous current at 12V DC for reliable switching performance
- Can be wired as normally open or normally closed to suit application needs
- Includes separate contacts for LED illumination, enabling indicator integration
- Easy installation with included .110-inch quick connect terminals and 19mm mounting hole
- High durability with approximately 18,000 switching cycles for demanding applications
- Temperature tolerant from -10°C to 70°C, suitable for varying environmental conditions
- Compact design with robust construction for marine, automotive, and industrial use
