Blue Sea Systems 7466 UL-489 30A Raised Rocker Circuit Breaker for Marine and Industrial Use

7466 UL-489 Circuit Breaker - 30A Raised Rocker

Suitable for use when UL-489 specifications are required (Navy, Army, or Coast Guard vessels, and other vessels covered under CFR 46)

Specifications:

• Amperage: 30A AC
• Actuator Style: Raised Rocker
• Poles: 2
• Maximum Voltage: 250V AC
• Circuit Breaker Type: Magnetic HydraulicTrip free
• Terminal Stud Torque: 35 in-lb (3.95 Nm)
• Interrupt Capacity: 5000A
• Minimum Operating Temperature: -40 C
• Maximum Operating Temperature: 85 C
• Mounting Screw: #6-32 SS
• Mounting Screw Torque: 8 in-lb (0.9 Nm)
• Switching Cycles: 10000
• Weight: 0.23lb (0.1 kg)

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The Blue Sea Systems 7466 UL-489 Circuit Breaker is designed to meet rigorous UL-489 standards, making it ideal for marine, military, and other demanding applications where safety and reliability are critical. This 30 Amp AC circuit breaker features a raised rocker actuator for easy operation and clear status indication. Its two-pole design allows for efficient circuit control, with a maximum voltage capacity of 250V AC, ensuring compatibility with a wide range of electrical systems. The magnetic hydraulic trip mechanism provides reliable protection against overloads and short circuits, with an interrupt capacity of 5000A to handle high fault currents safely. Built for durability, it can operate within a temperature range from -40°C to 85°C, making it suitable for harsh environments on vessels or outdoor installations. The breaker is mounted using #6-32 stainless steel screws, with a torque specification of 8 in-lb for secure installation. Its switching cycle capability of 10,000 ensures long-term performance with minimal maintenance needs. Weighing approximately 0.23 pounds, this circuit breaker offers a compact yet robust solution for electrical safety.

Note: This product may expose users to chemicals including di(2-ethylhexyl)phthalate (DEHP), which is recognized by California as a substance that can cause health issues. For detailed safety information, visit P65Warnings.ca.gov.

Features:

• UL-489 compliant for use in marine, military, and vessel applications

• 30 Amp AC current capacity with a maximum voltage of 250V AC

• Two-pole design for comprehensive circuit control

• Magnetic hydraulic trip mechanism for reliable overload protection

• Actuator style: Raised rocker for ease of use and clear status indication

• Operates within a temperature range from -40°C to 85°C for harsh environments

• Mounting with #6-32 stainless steel screws, torque specified as 8 in-lb

• High switching cycle capacity of 10,000 for durability

• Compact and lightweight design suitable for space-constrained installations
