Garmin ECHOMAP Ultra 2 16-Inch Chartplotter 166sv with GN+ Mapping (No Transducer)

ECHOMAP Ultra 2 16 Chartplotter 166sv with GN+ Mapping without Transducer

SEE BIGGER CATCHES ON A BIGGER SCREEN

Designed with the serious angler in mind, this 16-inch chartplotter with a full HD resolution display brings the ultimate in big-picture clarity, brightness, and readability to your navigation mapping and sonar returns. Select models come preloaded with Garmin Navionics+ mapping. Plus, theres support for the full line of LiveScope sonars1 as well as Ultra High-Definition scanning sonars and CHIRP traditional sonar.

LIVESCOPE SONAR SUPPORT

The ECHOMAP Ultra 2 chartplotter series supports the full lineup of LiveScope live-scanning sonar products (transducers sold separately).

BUILT-IN UHD SONAR

Select models are bundled with a GT56 transducer that provides Garmin CHIRP traditional sonar and Ultra High-Definition ClearV and SideV scanning sonars for photo-like images of whats beneath the surface.

PRELOADED CHARTS

Select units come with built-in Garmin Navionics+ mapping, which includes a 1-year subscription for daily updates, depth range shading, and more. For added features, Garmin Navionics Vision+ premium mapping is optionally available (sold separately).

HDMI OUTPUT

Use the chartplotters HDMI output connector to share your sonar screen with a TV or other external display.

VOICE CONTROL FEATURES

Built-in BLUETOOTH technology enables you to give voice commands to your chartplotter for hands-free control of such features as Force trolling motor modes, favorite keys, and sonar inputs.

VIVID COLOR PALETTES

High-contrast, vivid scanning sonar color palettes make it easier than ever to distinguish targets and structures.

WIRELESS NETWORKING

Share sonar3, waypoints, and routes with another ECHOMAP Ultra 2 or UHD2 plotter on board.

MULTI-BAND GPS

Get improved position accuracy with multi-band GPS

NMEA 2000 NETWORK COMPATIBILITY

Connect to heading sensors, autopilots, Fusion-Link audio systems, and more.

ACTIVECAPTAIN APP

Pair with the free smart-device app for software updates, screen recording, Garmin Quickdraw Community data, and more4.

FORCE TROLLING MOTOR

Wirelessly connect to your Force trolling motor to navigate to waypoints, draw and follow routes, and more.

SCREEN RECORDING

Use the recording feature through the ActiveCaptain app on your smartphone to share images from your chartplotter.

BAIL MOUNT WITH KNOBS

Surface mount your compatible ECHOMAP Ultra 2 chartplotter by using our bail mount with knobs; the mount tilts for optimum viewing.

Specifications:

• Dimensions: 16.9 x 10.5 x 3.14 (43.0 x 26.6 x 8.0 cm)


• Weight: 9.5 lbs (4.31 kg)


• Water rating: IPX7


• Touchscreen: Yes


• Display Type: FHD, IPS


• Display Size: 13.6 x 7.7; 15.6 diagonal (34.5 x 19.5 cm; 39.7 cm diagonal)


• Display resolution: 1920 x 1080 pixels


• Mounting Options: Bail or flush


• Input: Touchscreen with Keyed Assist


• Accepts Data Cards: 2 microSD cards


• Waypoints: 5000


• Track points: 50,000


• Tracks: 50 saved tracks


• Navigation Routes: 100


• Power Input: 9 to 18 Vdc


• Typical current draw at 12 Vdc: 3.9 A


• Maximum current draw at 12 Vdc: 6.6 A


• Maximum power usage at 10 Vdc: 48 W


• Traditional sonar (dual frequency/beam): built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP)


• ClearV: Built-in 260/455/800/1000/1200 kHz


• SideV: Built-in 260/455/800/1000/1200 kHz

Whats In The Box

• ECHOMAP Ultra 162sv or 166sv (depending on the version selected) with optional Garmin Navionics+


• Power cable


• Bail mount with knobs


• Protective sun cover


• Trim caps


• Hardware


• Documentation

1LiveScopeSystem sonar transducer sold separately2Via one-to-one unit wireless connection only3LiveScope sonar cannot be shared wirelessly between two ECHOMAP Ultra 2 or ECHOMAP UHD2 chartplotters4Requires the ActiveCaptain app on your compatible smartphone paired to your ECHOMAP Ultra 2 series chartplotter

The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc., and any use of such marks by Garmin is under license.

Engineering enhancements are ongoing and may not be reflected in the pictures, videos and specifications.

WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov.

The Garmin ECHOMAP Ultra 2 16-inch chartplotter series offers serious anglers a large, high-definition display for enhanced navigation and sonar imaging. Its full HD IPS touchscreen provides exceptional clarity, brightness, and readability, making it easier to spot fish and underwater structures even in challenging lighting conditions. Designed for versatile mounting options, the unit can be easily installed using the included bail mount with knobs or flush mount, ensuring a secure fit on your vessel. Equipped with a powerful multi-band GPS, the chartplotter delivers improved position accuracy for precise navigation across lakes, rivers, and coastal waters.

Select models come preloaded with Garmin Navionics+ mapping, which includes a one-year subscription for daily updates, depth shading, and other valuable features. For users seeking even more detailed charts, Garmin Navionics Vision+ premium mapping is available separately. The integrated UHD sonar capabilities, supported by the bundled GT56 transducer (sold separately), provide ultra high-definition imaging and traditional CHIRP sonar, offering photo-like images of what's beneath the water surface. The high-contrast, vivid color palettes make target and structure identification quick and intuitive.

The ECHOMAP Ultra 2 series supports the full line of LiveScope sonar transducers, enabling real-time, live-scanning views of underwater activity—ideal for serious anglers targeting specific fish or structures. Wireless sharing features allow you to transfer sonar data, waypoints, and routes between compatible units on your boat. With NMEA 2000 network compatibility, you can connect to heading sensors, autopilots, and audio systems for a fully integrated navigation experience. The built-in Bluetooth enables hands-free voice control, allowing you to manage key functions via voice commands for added convenience.

Additional features include HDMI output for external display sharing, support for two microSD cards for expanded storage, and the ActiveCaptain app for firmware updates, screen recording, and community data sharing. The unit's rugged design boasts an IPX7 water rating, making it suitable for use in various aquatic conditions. Whether on a freshwater lake or offshore, the Garmin ECHOMAP Ultra 2 16-inch chartplotter offers a comprehensive solution for navigation, sonar imaging, and connectivity, enhancing your fishing and boating experience.

Features:

• Large 16-inch full HD IPS touchscreen display for exceptional clarity and readability

• Preloaded Garmin Navionics+ charts with a one-year update subscription (select models)

• Supports full lineup of LiveScope live-scanning sonar (transducers sold separately)

• Built-in UHD sonar with traditional CHIRP and Ultra High-Definition ClearV and SideV scanning sonars

• Versatile mounting options including bail mount with knobs and flush mount

• Multi-band GPS for improved positional accuracy

• Wireless sharing of sonar data, waypoints, and routes with other compatible units

• Supports NMEA 2000 network for connectivity with heading sensors, autopilots, and audio systems

• Bluetooth technology with voice control for hands-free operation

• HDMI output for external display sharing

• Supports two microSD cards for expanded data storage

• IPX7 water rating for durability in wet conditions

• Compatibility with ActiveCaptain app for updates, screen recording, and community sharing

• Supports Garmin Force trolling motor for wireless waypoint and route navigation
