Blue Sea Systems 1228 120V AC 8-Position Circuit Breaker Panel with Backlit Labels

120 Volt AC 8 Position

Features:

• All circuit label positions are backlit

• "ON" indicating LEDs installed in all circuit positions

• Includes 4206-Square Format Label Set

Specifications:

• Positions: 8

• Nominal Voltage: 120V AC

• Maximum Amperage*: 100A

• Height: 7.75" (196.85mm)

• Width: 4.88" (123.95mm)

• Depth: 3.00" (76.2mm)

• Weight: 2.68lb (1.22kg)

* Maximum amperage ratings are dependent on use of appropriately sized fuses and wire for a given application.

Includes:
(8) - 7403 - A-Series Flat Rocker Circuit Breaker - Single Pole 15A
(1) - 4206 - Basic AC Label Kit - 30 Black Square Labels [LABEL]

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The Blue Sea Systems 1228 120V AC 8-Position Circuit Breaker Panel offers a reliable solution for managing multiple electrical circuits in both industrial and marine applications. Designed with user convenience in mind, this panel features all circuit label positions that are backlit, providing clear visibility in low-light environments. Each circuit position is equipped with an 'ON' indicating LED, ensuring quick and easy identification of active circuits. The panel includes a comprehensive 4206-Square Format Label Set, allowing users to customize and clearly identify each circuit for efficient operation and troubleshooting. Constructed for durability and performance, this panel supports a maximum amperage of 100A, making it suitable for a range of power distribution needs. Its compact size, with a height of approximately 7.75 inches, width of 4.88 inches, and depth of 3 inches, allows for flexible installation options without sacrificing functionality. The panel's weight of just over 2.5 pounds ensures it remains manageable during setup and maintenance. Designed specifically for 120V AC systems, the Blue Sea 1228 panel provides a robust interface for controlling multiple circuits in a safe and organized manner. The included flat rocker circuit breakers are rated at 15A for each of the eight positions, ensuring reliable overcurrent protection. This product is ideal for applications requiring a clear, organized, and visually accessible circuit management solution, such as on boats, RVs, or industrial setups. The panel's straightforward design and included labeling set make it easy to implement and maintain, reducing downtime and enhancing operational safety. For detailed installation instructions, refer to the owner’s manual available online via the provided link.

Features:

• Backlit circuit label positions for improved visibility

• 'ON' indicating LEDs installed in all circuit positions

• Includes 4206-Square Format Label Set for easy customization

• Supports up to 100A maximum amperage with proper wiring and fusing

• Compact design for flexible installation
