Description
WeatherDeck Water Resistant Circuit Breaker Panel
PN: 4374
Color: Gray
Features:
- Rated IP67-temporary immersion for 30 minutes
- Designed for flybridge and open cockpit applications
- Independent label backlighting allows switching and dimming
- Compatible with all Blue Sea Systems Digital Dimmers
- Each panel can be mounted in four different orientations
- Green LEDs aid low-light readability. All labels will be lit when the panel is powered, regardless of individual switch position.
Specifications:
- Weatherproof: Waterproof
- Positions: 4
- Nominal Voltage: 12v / 24v DC
- Circuit Protection: Circuit Breaker
- Maximum Amperage: 15A @ 12v DC (per circuit) / 9A @ 24v DC (per circuit)
- Panel Cumulative Rating: 45A
- Backlit Label: Green LED
- Backlighting Amperage: 10mA/Illuminated Circuit
- Backlighting Voltage: 12 or 24v DC
- Height: 4.3"
- Width: 4.25"
- Depth: 3.5"
Included:
- (4) 4135 Push Button Reset Only Circuit Breaker Boot - Clear
- (4) 4138 WeatherDeck Toggle Switch Boot - Black
- (4) 4150 WeatherDeck Toggle Switch SPST - ON-OFF
- (1) 4215 Waterproof DC Label Kit - 30 Black Square Labels V1
- (4) 7056 Push Button Reset Only Quick Connect Circuit Breaker - 15 Amps
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
The Blue Sea Systems 4374 WeatherDeck Water-Resistant Circuit Breaker Panel offers reliable protection and convenient control for marine applications, especially on flybridge and open cockpit vessels. Constructed with a durable gray housing, this panel is rated IP67, providing protection against temporary immersion in water for up to 30 minutes, making it ideal for challenging marine environments. Its sturdy design ensures consistent performance in harsh weather conditions, safeguarding your electrical circuits from water ingress and corrosion. The panel features four switch positions, each protected by a circuit breaker rated for 15 amps at 12 volts DC or 9 amps at 24 volts DC, with a total combined rating of 45 amps. It is compatible with all Blue Sea Systems digital dimmers, allowing seamless integration into existing marine electrical systems. The panel's independent label backlighting uses green LEDs, facilitating low-light readability and enabling easy switching and dimming. Additionally, the backlit labels illuminate all at once when the panel is powered, regardless of individual switch positions. The panel can be mounted in four different orientations, providing flexible installation options to suit various vessel layouts. Its compact dimensions make it suitable for tight spaces while maintaining accessibility and visibility. The package includes four weatherproof circuit breaker boots, toggle switch boots, toggle switches, waterproof labels, and quick-connect breakers, ensuring a comprehensive solution for marine electrical management. Whether for navigation lights, bilge pumps, or other critical systems, the Blue Sea Systems 4374 WeatherDeck panel delivers durability, safety, and ease of use in demanding marine environments. Designed to meet rigorous standards, this panel enhances both the functionality and safety of your vessel’s electrical system without compromising on reliability or convenience.
Features:
- Rated IP67 for water resistance, suitable for temporary immersion up to 30 minutes
- Designed specifically for flybridge and open cockpit marine applications
- Independent label backlighting with green LEDs for low-light visibility
- Compatible with all Blue Sea Systems Digital Dimmers
- Flexible mounting options with four different orientations
- Maximum circuit amperage of 15A at 12V DC and 9A at 24V DC per circuit
- Total panel capacity of 45A for multiple circuits
- Weatherproof and waterproof construction ensures durability in harsh marine environments
- Includes comprehensive accessories: circuit breaker boots, toggle switch boots, waterproof labels, and quick connect circuit breakers
