Blue Sea Systems 5050 ST CLB Circuit Breaker Block - 6-Position Distribution Panel

ST CLB Circuit Breaker Block - 6 Position

Features

• Quick connect clips allow circuit breakers to snap easily into place

• Tin-plated copper busses and screw terminals

• Clear insulating cover with square format label recesses, satisfies ABYC/USCG insulation requirements

• Easy to open clip on cover

• Breakouts allow wire access in two directions

• Accepts ring terminals

• Optional push button waterproof boots or dress nuts can be installed over cover

Specifications:
Circuits: 6
Maximum Amperage: 32A (per circuit) 40A (per jumped circuit group)
Maximum Voltage: 32V DC
Mounting: #8 Screw (M4) or #8 Nut
Source: Independent SourceMinimum Operating Temperature: -10 C
Maximum Operating Temperature: 60 C
Mounting Centers: 5.63"(143 mm)
Screw Terminal Type: #8-32 Screws with Captive Star Lock Washer
Height: 6.69"(169.93 mm)
Weight: 0.75lb (0.34 kg)

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The Blue Sea Systems 5050 ST CLB circuit breaker block is designed to simplify electrical distribution in marine, RV, and other DC power systems. Its six-position configuration allows for organized and reliable circuit management, supporting up to 32 amps per circuit and 40 amps in jumped circuit groups. This compact panel features quick connect clips that enable easy snap-in installation of circuit breakers, reducing setup time and ensuring secure connections. The tin-plated copper busbars and screw terminals provide excellent conductivity and corrosion resistance, suitable for demanding environments. A clear insulating cover with square label recesses meets ABYC and USCG insulation standards, ensuring safety and compliance in marine applications.

Features:

• Quick connect clips for secure and easy circuit breaker installation

• Tin-plated copper busbars and screw terminals for reliable conductivity

• Clear insulating cover with square format label recesses for easy identification and compliance

• Openable clip-on cover for convenient access and maintenance

• Breakouts allow wire access from two directions for flexible wiring options

• Accepts ring terminals for versatile wiring connections

• Optional waterproof boots or dress nuts can be installed over the cover for added protection
