Egis Mobile Electric Automatic Timer Disconnect 160A for 12V Vehicles

Automatic Timer Disconnect 160A - 12V

Prevents auxiliary loads from draining batteries, maximizing operational readiness by eliminating dead batteries, and reducing the total lifetime cost of vehicle use.

Ensures power after engine off or at the end of shift (video downloads) is available while automatically turning off after a preset time or if battery voltage is low.

Protects sensitive on-board electronics via optional under/over voltage shutdown and start event isolation.

Adjustable Time Delay: 0 sec - 4 hr, Optional Voltage Sense On/Off Trigger, Adjustable Low Voltage Off Trigger, Dip Switches On Top Side of Device

Features:

• Ultra-Low Power Draw: Lowest off-state current draw in industry (1.3 mA).
• Flexible Application Options: Install as a Time Delay Relay, Battery Management Relay, Low Voltage Disconnect, or Simple Relay. On/Off trigger via external Ignition signal and/or alternator voltage sense, and adjustable low voltage protection levels increase flexibility
• Simple Robust Installation: Sealed plug/harness included. Combined timer high-amp relay reduces install time/costs. The optional output bus bar connects RT or CT fuse blocks.
• Adjustable Optional OFF Time Delay: 0 seconds to 4 hours.
• Diagnostic Feedback via optional external LED and on-board LEDs
• Bullet-proof Construction: Sealed unit, high-temperature materials allow mounting anywhere on the vehicle. Integrated thermal overload protection.
• The optional kill switch eliminates the need for using thermal circuit breakers as service maintenance switches, reducing voltage drop to electrical loads.
• Meets Stringent OEM Standards for electrical transient self-protection
• 4 Year Industry-Leading Warranty

The Egis Mobile Electric Automatic Timer Disconnect Part Number 7615 is a versatile and reliable solution designed to optimize vehicle electrical systems. This 12V device prevents auxiliary loads from draining your vehicle’s main battery, ensuring maximum operational readiness and reducing overall vehicle maintenance costs. Its intelligent design allows it to automatically disconnect power after a preset time or when battery voltage drops below a specified threshold, maintaining battery health and preventing unexpected dead batteries during long periods of inactivity or after engine shutdown. The timer’s ability to provide power for essential functions such as video downloads or remote diagnostics even after the engine is off makes it an essential component for fleet vehicles and off-road equipment.

Constructed with durability in mind, the Egis Timer Disconnect features sealed, high-temperature materials suitable for mounting in any location on your vehicle. It includes an integrated thermal overload protection and optional under/over voltage shutdown to safeguard sensitive onboard electronics. Installation is simplified with a sealed plug and harness, and the device’s high-amp relay reduces installation time and costs. The optional output bus bar allows for clean connection to fuse blocks, further streamlining setup. The device offers a broad range of application options, functioning as a time delay relay, battery management relay, or low voltage disconnect, with adjustable trigger settings including time delay from zero seconds up to four hours, and voltage sensing controls that can be turned on or off as needed.

Additional features include diagnostic feedback via onboard LEDs and optional external indicators, a robust sealed design capable of withstanding harsh environments, and an optional kill switch that eliminates the need for thermal circuit breakers during service. This unit complies with stringent OEM standards for electrical transient protection, providing peace of mind in demanding operational conditions. Backed by a four-year industry-leading warranty, the Egis Mobile Electric Timer Disconnect is an essential upgrade for vehicle operators seeking reliable, flexible, and efficient electrical management.

Features:

• Ultra-low power draw at just 1.3 milliamps in the off state, conserving vehicle battery life.

• Flexible installation options including as a time delay relay, battery management relay, or low voltage disconnect with adjustable trigger settings.

• Sealed, robust construction with high-temperature materials and integrated thermal overload protection for reliable performance in harsh environments.

• Adjustable off time delay from zero seconds up to four hours to suit various operational needs.

• Diagnostic feedback provided through onboard LEDs and optional external indicators for easy troubleshooting and system monitoring.
