Egis Mobile Electric Triple Battery Advanced Automatic Charging Relay (ACR) - 24V

Triple Battery Advanced Automatic Charging Relay (ACR) - 24V

Two Independent ACRs in One Device reduce installation space and time. Significantly lowers the out-of-state current draw.

Features:

• Eliminates Dead Start Batteries by sharing charge sources with all batteries and isolating batteries when no charge sources are present
• Simple Robust Installation:Integrated sealed plug eliminates corrosion, includes DT04 harness. A single device reduces installation time, space, cost, and points of potential failure
• An additional low-amp output can be used to report device status remotely.
• Bullet-proof Construction: Sealed unit, high-temperature materials allow mounting anywhere. Integrated thermal overload shutdown protection
• Ultra Low Off-State Current: Compare two typical ACRs (20 mA) vs Dual ACR @ 1.3 mA
• Adjustable Off-Voltage for Auxiliary Battery Priority provides the ability to share start battery energy for auxiliary without risking engine starting ability.
• Start/Engine Isolation input option for ensuring sensitive electronics do not experience voltage sags and spikes from the cranking event.
• Start Assist input option to ensure maximum cranking amps available when necessary.
• 4 Year Industry-Leading Warranty

The Egis Mobile Electric Triple Battery Advanced Automatic Charging Relay (ACR) for 24V systems offers a compact, efficient solution for managing multiple batteries in automotive and RV applications. Featuring two independent ACRs within a single device, it reduces installation space and simplifies wiring, while effectively lowering out-of-state current draw to enhance battery life and system reliability. This advanced relay eliminates dead start batteries by sharing charge sources among all batteries and isolating them when no charge is available, ensuring consistent power availability. Its robust, sealed construction with high-temperature materials allows mounting in any environment, and the integrated thermal overload shutdown provides added protection against overheating. The included sealed plug and DT04 harness streamline installation, reducing time, space, and potential points of failure, making it ideal for both professional and DIY setups. An auxiliary, low-amp output facilitates remote status monitoring, enabling proactive system management without additional components. The Egis ACR features adjustable off-voltage settings to prioritize auxiliary battery charging, ensuring the start battery's readiness without risking engine start capability. Additional inputs for start/engine isolation and start assist allow for custom integration with sensitive electronics and cranking systems, improving overall vehicle performance. Backed by a four-year industry-leading warranty, this relay combines durability, efficiency, and ease of installation, making it a reliable choice for complex power management systems in vehicles requiring 24V operation.

Features:

• Eliminates dead start batteries by sharing charge sources and isolating batteries when no charge is present

• Simple, robust installation with integrated sealed plug and included harness to reduce installation time and points of failure

• Additional low-amp output for remote device status reporting

• Sealed, high-temperature resistant unit with thermal overload shutdown protection for versatile mounting

• Ultra low off-state current at approximately 1.3 mA compared to typical 20 mA ACRs

• Adjustable off-voltage for auxiliary battery priority to optimize charging without compromising engine start power

• Start/engine isolation input to protect sensitive electronics from voltage fluctuations during cranking

• Start assist input for maximum cranking amps when necessary

• Four-year industry-leading warranty ensuring long-term reliability
