Garmin GPSMAP 9017 Premium Chartplotter with 4K Touchscreen and Worldwide Basemap

GPSMAP 9017 Premium Chartplotter with Worldwide Basemap

PARADISE STARTS HERE

Its the integrated 4K touchscreen chartplotter for captains and anglers who demand the best. Enjoy edge-to-edge clarity and luxury on a glass helm with premium design and materials.

Features:

• Premium IPS sunlight-readable touchscreen display


• Up to 7 times faster processing power than previous generations


• Get clarity like never before on a 4K display


• Supports Garmin Navionics+ charts with Auto Guidance+ technology¹



• Gigabit speeds on the Garmin Bluenet network


• Network with multiple chartplotters, cameras, and more

Premium Chartplotter

The 4K IPS sunlight-readable touchscreen display and edge-to-edge design provide a seamless and luxurious modern look.

Faster. Much Faster.

Processing power is 7 times faster than previous generations for superior performance; draw charts quickly, and calculate Auto Guidance+ routes¹ with lightning speed with an optional Garmin Navionics+ subscription.

Garmin Bluenet Network

Build extensive networks with multiple chartplotters, cameras, radars, and sonars and enjoy gigabit-speed

EntertainmentOptions

Enjoy audio and video integrations that allow you to show and hear the same video throughout the screens and speakers on your network.

Garmin Sailassist Sailing Features and Sailing Polars

View laylines, race start line guidance, enhanced wind rose, heading and course-over-ground lines, true wind data fields and tide/current/time slider, and more. Plus, the polar table shows key data, so you know whether you need to adjust sail trim.

Connect Your Ecosystem

Take command through digital system integrations to monitor, automate, and control your vessel. The chartplotter uses the NMEA 2000 network to connect to your compatible accessories.

Connect

• Software Updates: Get wireless software updates via the ActiveCaptain app with your compatible smartphone or tablet.


• Engine Monitoring: Keep tabs on engine performance with extensive engine integration.


• Custom Look: Manufacturers can customize the homepage layout and splash screen for a brand-tailored experience.

Navigate

• Mapping: Navigate with optional Garmin Navionics+ charts that include Auto Guidance+ technology, daily updates, and more¹ (subscription required).


• Premium Charts: Get support for Garmin Navionics Vision+ charts with premium relief shading and satellite imagery.


• Know Where You Are: Get your precise location with the built-in dual-frequency 10 Hz GPS.


•
  Autopilot:Control the autopilot with any compatible chartplotter on the network with autopilot integration.

Integrate

• Connect Cameras: Get extensive camera support and control to see footage directly on the chartplotter.


• Control with Your Watch: Connect to your chartplotter with your compatible Garmin smartwatch.


• Wireless Connectivity: Connect compatible devices with integrated Bluetooth and ANT technologies.


• Fish Mapping: Get comprehensive fishing data with the Fish Mapping feature from SiriusXM Radio (accessory purchase and subscription required).


• Verbal Commands: Use spoken commands to control the chartplotter through your compatible headset or quatix smartwatch.


• Weather-Resistant:


• The GPSMAP 9000 chartplotter is built for harsh marine conditions with an IPX7 water-resistance rating.

Whats In The Box

• GPSMAP 9017 premium chartplotter


• Power cable


• Backbone/drop cable (2 meters) and T-connector for the NMEA 2000 Network


• Flush mount kit


• Protective cover


• Trim piece snap covers


• Documentation

Specifications:

General:

• Dimension: 16.80 x 11.23 x 3.60


• Weight: 13.0 lbs


• Water Rating: IPX7


• Touchscreen: Yes


• Display Type: 4K, IPS; Mini LED (Local Dimming) backlight


• Display Size: 15.04 x 8.50 x 17.25 diagonal


• Display Resolution: 3840 x 2160 pixels


• Mounting Options: flat or flush


• Input: Touchscreen


• Polarized Lens Viewability: Yes

Maps Memory:

• Accepts Data Cards: 2 microSD cards (on rear of product)


• Supports USB Card Reader: Yes


• Waypoints: 5,000


• Track Points: 50,000


• Tracks: 50 saved tracks


• Navigation Routes: 100

Sensors:

• GPS: Yes


• GLONASS: Yes


• GALILEO: Yes


• BEIDOU: Yes


• Has Built-in Receiver: Yes


• Receiver: 10 Hz


• NMEA 2000 Compatible: Yes


• NMEA 0183 Compatible: Yes


• Supports WAAS: Yes


• Supports Multi-Band, Multi-Constellation GPS: Yes

Chartplotter Features:

• Smart Mode Compatible: Yes


• AIS: Yes


• DSC: Yes


• Supports Fusion-Link Compatible Radios: Yes


• GCV Black Box Sonar Support: Yes


• Activecaptain Compatible: Yes


• Supports Voice Commands: Yes


• GRID (Garmin Remote Input Device) Compatible: Yes


• GRID 20 Compatible: Yes


• Wireless Remote Compatible: Yes


• Sailing Features: Yes


• Spoken Audio Alerts: Yes


• Onehelm Support: Yes

Electrical Features:

• Power Input: 10 to 32 Vdc


• Typical Current Draw at 12Vdc: 4.3A


• Maximum Current Draw at 12Vdc: 1.9A


• Maximum Power Usage at 10Vdc: 52w

Connections:

• NMEA 2000 Ports: 1


• NMEA 0183 Input (RX) Ports: 1


• NMEA 0183 Output (TX) Ports: 1


• Video Input Ports: 1 (BNC composite); 1 HDMI (HDCP compliant)


• Video Output Ports: 1 HDMI


• J1939 Ports: 1


• Garmin Bluenet Networks Ports: 2


• USB Ports: yes (1x USB-C)


• Bluetooth Pairing: Yes


• ANT (Connectivity): Yes


• Garmin Wi-Fi Network (Local Connection): Yes


• Wi-Fi Frequency Bands: 2.4 GHz 5 GHz


• Audio Output: Yes

^{1Auto Guidance+ is for planning purposes only and does not replace safe navigation operations}

WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov.

The Garmin GPSMAP 9017 Premium Chartplotter offers a sophisticated navigation solution designed for serious sailors and anglers. Featuring a 15-inch diagonal 4K IPS sunlight-readable touchscreen with edge-to-edge glass, this chartplotter provides exceptional clarity and a modern aesthetic for your vessel's helm. The high-resolution display, combined with a mini LED backlight, ensures optimal visibility in all lighting conditions, making navigation and data monitoring effortless. Its robust build with an IPX7 water resistance rating guarantees durability even in harsh marine environments, ensuring reliable performance during long voyages or challenging weather.

Powered by up to seven times faster processing than previous models, the Garmin GPSMAP 9017 delivers rapid chart rendering and swift route calculations, including Auto Guidance+ technology support, which simplifies navigation planning. The device supports Garmin Navionics+ charts and Garmin Navionics Vision+ charts for detailed mapping, satellite imagery, and premium relief shading. Its built-in dual-frequency 10 Hz GPS provides precise positioning, vital for accurate navigation and wayfinding. The system seamlessly connects to the Garmin BlueNet network, enabling gigabit speeds for networked chartplotters, cameras, radars, and sonars, creating an integrated marine environment.

The chartplotter supports extensive connectivity options, including wireless updates via the ActiveCaptain app, Bluetooth, ANT, and Wi-Fi, allowing control through compatible Garmin smartwatches and smartphones. It offers advanced sailing features like laylines, race start guidance, wind rose, tide and current data, and polar tables to optimize sailing performance. Additional integrations include camera support, engine monitoring, and customizable user interfaces, giving vessel operators comprehensive control over their onboard systems. With its support for AIS, DSC, and Fusion-Link radios, the GPSMAP 9017 enhances safety and communication on the water. The device also supports voice commands and verbal alerts for hands-free operation.

Included with the device are the chartplotter unit, power and backbone cables, flush mount kit, protective cover, and comprehensive documentation, ensuring straightforward installation and operation. Whether used for navigation, fishing, or sailing, the Garmin GPSMAP 9017 Premium Chartplotter combines cutting-edge technology with durability and ease of use, making it a top choice for serious marine enthusiasts and professionals alike.

Features:

• Premium 15-inch 4K IPS sunlight-readable touchscreen display with edge-to-edge glass

• Processing speed up to 7 times faster than previous models for rapid chart rendering and route calculation

• Supports Garmin Navionics+ and Vision+ charts with Auto Guidance+ technology

• Built-in dual-frequency 10 Hz GPS for precise positioning

• Supports Garmin BlueNet network for gigabit speeds and networked device integration

• Weather-resistant with IPX7 rating for durability in harsh marine conditions

• Wireless software updates via ActiveCaptain app for easy maintenance

• Comprehensive sailing features including laylines, race start guidance, wind rose, and tide data

• Support for AIS, DSC, Fusion-Link radios, and camera integrations

• Control via compatible Garmin smartwatches and voice commands for hands-free operation
