Blue Sea Systems 1200 12V DC Vertical 8-Position Power Distribution Panel

12 Volt DC 8 Position - Vertical

Features:

• 4 to 32 branch circuits with installed 15 Ampere circuit breakers

• Available with voltmeters, ammeters, and digital multimeters

• Includes 4205-Square Format Label Set

Specifications:

• Positions: 8

• Nominal Voltage: 12V DC

• Maximum Amperage*: 100A

• Height: 7.75" (196.85mm)

• Width: 4.88" (123.95mm)

• Depth: 3.00" (76.2mm)

• Weight: 2.60lb (1.18kg)

* Maximum amperage ratings are dependent on use of appropriately sized fuses and wire for a given application.

Includes:
(8) - 7403 - A-Series Flat Rocker Circuit Breaker - Single Pole 15A
(1) - 4205 - Basic DC Label Kit - 30 Black Square Labels [LABEL]

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The Blue Sea Systems 1200 is a versatile and reliable 12 Volt DC power distribution panel designed for efficient circuit management in marine, RV, and industrial applications. Featuring eight vertical positions, this panel allows for organized and accessible circuit connections. Its robust construction supports 4 to 32 branch circuits, each protected by 15 Ampere circuit breakers, providing safe and customizable power distribution. The panel can be equipped with voltmeters, ammeters, and digital multimeters for real-time monitoring of electrical parameters, ensuring optimal system performance and safety. Included with the panel is the 4205-Square Format Label Set, allowing users to clearly identify circuits and enhance operational clarity. The design emphasizes durability with a compact footprint, making it suitable for confined spaces while supporting a maximum amperage of up to 100A, depending on fuse and wire ratings. The panel’s dimensions are compact yet sturdy, with a height of approximately 7.75 inches, width of 4.88 inches, and depth of 3 inches, weighing just over 2.6 pounds for easy installation and handling. This power panel is an essential component for anyone looking to organize and protect their electrical system efficiently. The package includes eight single-pole 15A circuit breakers, a basic DC label kit with 30 black square labels, and comprehensive documentation for installation and operation. Designed with safety in mind, it complies with industry standards and features warning labels about potential chemical exposure, specifically di(2-ethylhexyl)phthalate (DEHP). The Blue Sea 1200 ensures reliable power management with a professional-grade build quality suitable for demanding environments.

Features:

• Supports 4 to 32 branch circuits with installed 15 Ampere circuit breakers

• Available with voltmeters, ammeters, and digital multimeters for comprehensive monitoring

• Includes 4205-Square Format Label Set for circuit identification

• Maximum amperage support up to 100A depending on fuse and wire ratings

• Compact vertical design with eight circuit positions for organized wiring
