Blue Sea Systems 1457 8-Position Vertical Switch Panel with Voltmeters and Ammeters

8 Position Switch CLB Vertical

Features:

• Available with voltmeters and ammeters

• Panels with meters include a toggle switch to monitor voltage on up to three battery banks

• Includes 4205-Square Format Label Set

Specifications:

• Positions: 8

• Nominal Voltage: 12V DC

• Maximum Amperage*: 80A

• Height: 7.75" (196.85mm)

• Width: 4.88" (123.95mm)

• Depth: 3.50" (88.9mm)

• Weight: 1.69lb (0.77kg)

* Maximum amperage ratings are dependent on use of appropriately sized fuses and wire for a given application.

Includes:
(8) - 7480 - Rocker Switch SPST - ON-OFF
(8) - 7054 - Push Button Reset Only Quick Connect Circuit Breaker - 10 Amps
(1) - 4205 - Basic DC Label Kit - 30 Black Square Labels [LABEL]

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The Blue Sea Systems 1457 8-Position Vertical Switch Panel offers a versatile solution for managing multiple battery banks in marine, RV, and industrial applications. Designed with eight switch positions, this panel allows users to easily switch between different power sources or configurations. It is available with optional voltmeters and ammeters, providing real-time monitoring of voltage and current to ensure optimal system performance. The inclusion of a toggle switch enables monitoring of up to three separate battery banks, making it suitable for complex power management systems. The panel comes with a 4205-Square Format Label Set, allowing for clear and customizable labeling of each switch for quick identification.

Features:

• Available with voltmeters and ammeters for comprehensive system monitoring

• Includes a toggle switch to monitor voltage on up to three battery banks

• Panel features eight positions for flexible power management

• Comes with a 4205-Square Format Label Set for easy customization

• Constructed for 12V DC systems with a maximum amperage of 80A, dependent on appropriate wiring and fusing
