Description
7155 Short Stop Circuit Breaker - 30A
- Corrosion Resistant Material
- IP 64 Water Resistant Boot
- Push to Reset Only
- Interrupt Capacity: 2,500A @ 28VDC
- Red insulating boot included in retail package
Specifications
- Amperage: 30A DC
- Maximum Voltage: 28V DC
- Interrupt Capacity: 2500A @ 28V DC
- Minimum Operating Temperature: -10 C
- Maximum Operating Temperature: 60 C
- Screw Terminal Torque: 24 in-lb (2.71 Nm)
- Terminal Stud: #10-32"
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
The Blue Sea Systems 7155 Short Stop Circuit Breaker is designed for reliable overcurrent protection in DC electrical systems, offering a 30A current rating. Constructed with corrosion-resistant materials, this breaker ensures longevity in harsh environments. Its IP 64 water-resistant boot provides additional protection against moisture and dust, making it suitable for marine, automotive, and industrial applications. The push-to-reset mechanism simplifies operation, allowing quick restoration after tripping. With an interrupt capacity of 2,500A at 28VDC, it effectively safeguards connected equipment from high-current faults while maintaining a compact form factor suitable for tight spaces.
The circuit breaker features a #10-32
