Blue Sea Systems 7546 C-Series Flat Rocker Circuit Breaker – Single Pole, 50A

• Rocker actuator is flush in the "ON" position, eliminating the risk of accidential switching

• Color actuator indicates "OFF" position

• Provides overcurrent protection for inverters, bow thrusters, and windlasses

• Combines switching and circuit protection into a single device

• "Trip Free" - cannot be held closed after trip

• Ignition protectedsafe for installation aboard gasoline powered boats

• Amperage: 50A AC / 50A DC

• Actuator Style: Flat Rocker

• Poles: 1

• Maximum Voltage: 240V AC / 48V DC

• Circuit Breaker Type: Magnetic Hydraulic - trip free

• Terminal Stud Torque: 35 in-lb (3.95 Nm)
• Interrupt Capacity: 3000A @ 120V AC / 3500A @ 240V AC / 5000A @ 32V DC

• Minimum Operating Temperature: -40 C

• Maximum Operating Temperature: 85 C

• Mounting Screw: #6-32 Stainless Steel

• Mounting Screw Torque: 6 in-lb (0.68 Nm)

• Switching Cycles: 10000

• Terminal Stud: 1/4-20 Tin-Plated Brass

• Weight: 0.38lb (0.17 kg)

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The Blue Sea Systems 7546 C-Series Flat Rocker Circuit Breaker is designed for reliable overcurrent protection in marine electrical systems. Featuring a flush-mounted rocker actuator, it ensures the switch remains securely in the "ON" position, reducing the risk of accidental disconnection. The actuator's color-coded indicator clearly displays the "OFF" position for quick visual confirmation. This single-pole breaker is suitable for protecting inverters, bow thrusters, windlasses, and other critical marine equipment, combining switching and circuit protection into a single compact device. Its magnetic hydraulic trip-free design ensures it cannot be held closed after tripping, providing added safety and protection during fault conditions. The breaker is ignition protected, making it safe for installation on gasoline-powered boats, and it supports both AC and DC applications with a maximum voltage of 240V AC or 48V DC. The durable construction includes stainless steel mounting screws and tin-plated brass terminal studs, supporting up to 10,000 switching cycles for long-term reliability. It also features high interrupt capacity, with ratings up to 5000A at 32V DC and over 3000A at 120V AC, ensuring it can handle large fault currents. The breaker's temperature operating range spans from -40°C to 85°C, making it suitable for various marine environments. Its compact size and lightweight design facilitate easy installation and maintenance, making it an ideal choice for boat electrical systems requiring robust circuit protection with reliable switching performance.

Features:

• Flush-mounted rocker actuator prevents accidental switching

• Color-coded actuator indicates "OFF" position for quick identification

• Provides overcurrent protection for marine equipment such as inverters and windlasses

• Combines switching and circuit protection in a single device

• "Trip Free" design ensures breaker cannot remain closed after trip for safety

• Ignition protected for safe installation aboard gasoline-powered boats

• Supports both AC and DC applications with high interrupt capacity

• Durable construction with stainless steel mounting screws and tin-plated brass terminals

• Supports up to 10,000 switching cycles for extended reliability

• Compact and lightweight design simplifies installation and maintenance
