Blue Sea Systems A-Series Flat Rocker Circuit Breaker - Single Pole 2.5A

• Rocker actuator is flush in the "ON" position, eliminating the risk of accidential switching

• Color actuator indicates "OFF" position

• "Trip Free" design cannot be held "ON" during fault current condition

• 2 different actuator styles available

• Prevents accidental switching of 24 hour circuits

• International ON/OFF symbols support vertical or horizontal mounting

• Amperage: 2.5A DC / 2.5A AC

• Actuator Style: Flat Rocker

• Poles: 1

• Max Voltage:250V AC / 32V DC

• Circuit Breaker Type: Magnetic Hydraulic - Trip Free

• Interrupt Capacity: 3000A @ 125V AC / 1500A @ 250V AC / 5000A @ 32V DC

• Minimum Operating Temperature: -40 C
• Maximum Operating Temperature: 85 C
• Mounting Screw: #6-32 Stainless Steel
• Mounting Screw Torque: 6 in-lb (0.68 Nm)
• Screw Terminal Torque 14 in-lb (1.58 Nm)
• Switching Cycles: 10000
• Terminal Screw: #10-32 Stainless Steel
• Weight: 0.21lb (0.1 kg)

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The Blue Sea Systems A-Series Flat Rocker Circuit Breaker (Part Number 7399) is designed for reliable circuit protection in both AC and DC applications with a rated current of 2.5 amps. Featuring a flush-mounted rocker actuator, this breaker reduces the risk of accidental switching by keeping the actuator securely in the "ON" position, while the color-coded actuator clearly indicates the "OFF" state for quick visual identification. Its "trip free" design ensures that the breaker cannot be held "ON" during a fault condition, providing enhanced safety and protection for your electrical system. The breaker accommodates both vertical and horizontal mounting orientations, supported by international ON/OFF symbols that facilitate easy installation in various configurations. Constructed with stainless steel mounting and terminal screws, this breaker is built for durability and long-term performance. It supports up to 10,000 switching cycles, making it suitable for demanding applications that require consistent operation over time. The maximum voltage ratings are 250V AC and 32V DC, with interrupt capacities of up to 3000A at 125V AC, ensuring safe disconnection during overcurrent events. Operating within a temperature range from -40°C to 85°C, it is ideal for a wide variety of environments. The breaker's compact design weighs approximately 0.21 pounds, making it a versatile addition to your electrical system. Please note that this product contains chemicals known to cause reproductive harm, and appropriate safety measures should be observed during installation and handling.

Features:

• Flush-mounted flat rocker actuator reduces accidental switching risk

• Color-coded actuator indicates OFF position for easy identification

• Trip free design prevents holding the breaker ON during faults

• Supports vertical or horizontal mounting with international symbols

• Designed for durability with stainless steel screws and high switching cycle count

• Supports up to 3000A interrupt capacity and 10,000 switching cycles

• Rated for 250V AC and 32V DC applications with reliable overcurrent protection
