Blue Sea Systems 7547 C-Series Flat Rocker Circuit Breaker - Single Pole 60A

• Rocker actuator is flush in the "ON" position, eliminating the risk of accidential switching

• Color actuator indicates "OFF" position

• Provides overcurrent protection for inverters, bow thrusters, and windlasses

• Combines switching and circuit protection into a single device

• "Trip Free" - cannot be held closed after trip

• Ignition protectedsafe for installation aboard gasoline powered boats

• Amperage: 60A AC / 60A DC

• Actuator Style: Flat Rocker

• Poles: 1

• Maximum Voltage: 240V AC / 48V DC

• Circuit Breaker Type: Magnetic Hydraulic - trip free

• Terminal Stud Torque: 35 in-lb (3.95 Nm)
• Interrupt Capacity: 3000A @ 120V AC / 3500A @ 240V AC / 5000A @ 32V DC

• Minimum Operating Temperature: -40 C

• Maximum Operating Temperature: 85 C

• Mounting Screw: #6-32 Stainless Steel

• Mounting Screw Torque: 6 in-lb (0.68 Nm)

• Switching Cycles: 10000

• Terminal Stud: 1/4-20 Tin-Plated Brass

• Weight: 0.38lb (0.17 kg)

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The Blue Sea Systems 7547 C-Series Flat Rocker Circuit Breaker offers reliable overcurrent protection for your marine electrical systems. Designed for use with inverters, bow thrusters, and windlasses, this single-pole breaker combines switching and circuit protection into a compact, easy-to-operate device. Its flush-mounted rocker actuator minimizes accidental switching, providing peace of mind during operation. The breaker features a clear color indicator for the "OFF" position, enhancing safety and visibility. With a trip-free design, it cannot be held closed after tripping, ensuring proper circuit protection and safety in critical situations.
Constructed to handle up to 60 amps of both AC and DC current, this breaker supports maximum voltages of 240V AC and 48V DC. Its magnetic hydraulic trip mechanism responds quickly to overloads, preventing potential damage to your equipment. The unit is built with robust components, including a 1/4-20 tin-plated brass terminal stud and stainless steel mounting screws, ensuring durability in harsh marine environments. It can withstand a wide temperature range from -40°C to 85°C, making it suitable for various weather conditions. The breaker is rated for 10,000 switching cycles, providing long-term reliable operation. Its compact size and lightweight design make installation straightforward and unobtrusive.
Designed with safety and performance in mind, the Blue Sea Systems 7547 is a versatile solution for marine electrical protection needs. It is ignition protected, making it safe for installation aboard gasoline-powered boats. This breaker not only enhances safety but also simplifies wiring with its terminal stud torque of 35 in-lb and mounting screw torque of 6 in-lb. Whether you're upgrading your boat's electrical system or installing new circuits, this breaker provides dependable protection and easy operation for demanding marine applications.

Features:

• Flush-mounted rocker actuator reduces accidental switching risk

• Color indicator clearly shows "OFF" position

• Provides overcurrent protection for marine inverters, bow thrusters, and windlasses

• Combines switching and circuit protection into a single compact device

• "Trip Free" design prevents holding the breaker closed after tripping

• Ignition protected for safe installation aboard gasoline-powered boats

• Rated for 60A AC and DC current at up to 240V AC / 48V DC

• Magnetic hydraulic trip mechanism ensures quick response

• Durable construction with stainless steel mounting screws and brass terminal studs

• Operates reliably within temperature ranges from -40°C to 85°C

• Supports up to 10,000 switching cycles for long-term durability
