Lenco Marine LED Indicator Integrated Tactile Switch Kit with Pigtail for Dual Actuator Systems

LED Indicator Integrated Tactile Switch Kit with Pigtail for Dual Actuator Systems

Complete your Lenco trim tab system with the latest, maintenance-free (ALL-IN-ONE) integrated tactile switch kit design. This NEW switch technology improves accuracy and integrates the control box functionality into the key pad bezel.

LED indicator lights let you know exactly where your trim tabs are at all times. A backlit keypad automatically illuminates graphics for night viewing. A photo eye reads ambient light and adjusts the indicator intensity for optimum viewing in all lighting conditions.

Features Include

• Simple, quick, Plug Play installation
• Instant response
• Built-in retractor
• Low profile design
• Self-contained key pad with waterproof Plug Play Deutsch connectors
• Wiring harness length 30" (76.2 cm) from the back of the switch bezel
• 36" power pigtail
• 2 1/16" hole cut-out size, overall key pad size of 2.75" x 2.75"
• 4.08" clearance required from the back of the key pad's mounting location
• 2 high-intensity LED Indicator displays show the exact position of your trim tabs at all times
• Photo Eye for optimum viewing in all light conditions
• Backlit key pad for optimum viewing at night

Replacement parts are available and are sold separately.

Specifications

• 3 Year Warranty
• System Type:Dual Actuator
• Compliance:CE Certified

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Enhance your Lenco trim tab system with the Lenco Marine Part Number 15171-001 LED Indicator Integrated Tactile Switch Kit, designed specifically for dual actuator applications. This all-in-one, maintenance-free switch kit features a modern, low-profile design that seamlessly integrates into your boat's control panel, providing reliable operation and a sleek appearance. The kit includes a self-contained waterproof keypad with Deutsch connectors, ensuring a quick and straightforward plug-and-play installation that minimizes setup time and complexity. Its wiring harness extends approximately 30 inches from the back of the bezel, accommodating versatile mounting options, with the power pigtail measuring 36 inches for added flexibility in wiring configurations.

The tactile switch is equipped with high-intensity LED indicators that accurately display the current position of your trim tabs at all times, providing visual confirmation regardless of lighting conditions. The illuminated keypad features a photo eye sensor that automatically adjusts the backlight intensity, ensuring optimal visibility during both day and night. This feature enhances safety and convenience, especially when operating in low-light environments. The switch's instant response capability ensures precise control over your dual actuators, allowing for smooth, coordinated movements essential for optimal boat handling.

Designed to fit a 2 1/16-inch hole with an overall keypad size of 2.75 inches by 2.75 inches, the kit requires a minimum of 4.08 inches of clearance behind the mounting surface. It includes a built-in retractor for durability and longevity, supporting seamless operation under demanding conditions. The system is CE certified, backed by a 3-year warranty, and parts are available separately for easy replacement or upgrades. This switch kit is ideal for boat owners seeking a reliable, high-quality control solution that combines advanced features with straightforward installation, ensuring improved trim tab management and enhanced boat performance.

Note that this product may not be returned to the point of purchase, and any issues should be directed to the manufacturer. It also contains chemicals known to the State of California to cause reproductive harm, as detailed in the P65Warnings.gov link.

Features:

• Simple, quick, Plug and Play installation

• Instant response for precise control

• Built-in retractor for durability

• Low profile design for unobtrusive mounting

• Waterproof self-contained keypad with Deutsch connectors

• Wiring harness length of 30 inches for flexible installation

• 36-inch power pigtail included

• Fits a 2 1/16-inch hole with overall size of 2.75 x 2.75 inches

• Requires at least 4.08 inches of clearance behind mounting surface

• High-intensity LED indicators display trim tab position

• Photo eye sensor adjusts backlight for optimal viewing

• Backlit keypad for nighttime operation
