Description
102 XD Actuator- 12 Volt- 4-1/2 Stroke with Mounting Hardware
The 102 XD Actuator is used with Trolling Tab systems sold after 2000 and OEM applications. 4.25 stroke. Overall length (tip to tip) is 13 inches. Instant response electric actuators are made of high impact glass fiber filled, ultraviolet-resistant nylon material with 316 super buff stainless steel tubing.
Specifications:
- Newly implemented Anti Extrusion Ring (AXR) seal stabilization system.
- Stronger top cap and mounting clevis design
- Improved pressure-tight torx screws
- Integrated wiper seal at actuator base
- Molded-in brass thrust bearing design
- Thicker and stronger motor housing wall
- Improved O-Ring design for more consistent seal
- Over-molded cable providing a stronger tighter seal
- Upper mounting bracket with gland seal
Features:
- Lenco's ballscrew design is more reliable and twice as powerful compared to typical hydraulics
- Lenco's tough, high-torque actuator motor easily pushes 500 pounds.
- Lenco Actuator connections use waterproof "Plug Play" Deutsch connectors eliminating the possibility of water intrusion.
- 12 Volt
- 5/16" mounting hardware
- 6 foot cable
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
The Lenco Marine 102XD Extreme Duty Electric Actuator is designed for reliable operation in trolling tab systems and OEM applications, especially for models manufactured after 2000. With a 4-1/4 inch stroke and an overall length of approximately 13 inches, this actuator offers precise and responsive control for your marine needs. Constructed from high-impact glass fiber filled, ultraviolet-resistant nylon and reinforced with 316 stainless steel tubing, the 102XD ensures durability and resistance to harsh marine environments.
Key enhancements include a newly implemented Anti Extrusion Ring (AXR) seal stabilization system that improves sealing performance and longevity. The actuator features a robust top cap and mounting clevis design, along with improved pressure-tight torx screws for added strength. An integrated wiper seal at the base prevents dirt and water ingress, while a molded-in brass thrust bearing offers smooth operation. The thicker, reinforced motor housing enhances durability, and an upgraded O-ring ensures a consistent seal. The over-molded cable provides a tighter, more reliable connection, and the upper mounting bracket with gland seal simplifies installation.
Designed with reliability in mind, the Lenco 102XD boasts a ballscrew drive system that is more dependable and twice as powerful as typical hydraulic systems. Capable of pushing loads up to 500 pounds, its high-torque motor is suitable for demanding marine applications. Waterproof Deutsch "Plug & Play" connectors eliminate water intrusion risks, and a 6-foot cable allows flexible installation options. This electric actuator is powered by 12 volts and includes 5/16-inch mounting hardware for secure attachment.
Note that this product contains chemicals such as di(2-ethylhexyl)phthalate (DEHP), which are recognized by California’s Proposition 65 as potential reproductive hazards. For more information, visit P65Warnings.ca.gov. Please be aware that this product may not be returned to the point of purchase, and any issues should be directed to the manufacturer directly for assistance.
Features:
- Lenco's ballscrew drive is more reliable and twice as powerful compared to typical hydraulic actuators
- High-torque motor capable of pushing up to 500 pounds
- Waterproof Deutsch "Plug & Play" connectors prevent water intrusion
- Powered by 12 volts with a 6-foot cable for flexible installation
- Includes 5/16-inch mounting hardware for secure attachment
