Explore E2 Narrow Beam - Midnight Blue
The E2 is our latest addition to the Explore range, giving customers a compact smaller XFM light for tight installation spaces, but with all the build quality and premium features of the larger lights in the range.
Choice of Beam
With the E2, you can choose either the signature Explore Series wide-angle beam
(90 x 20 Elliptical), or a new narrow laser beam shape (20 Circular), depending on your desired effect.
Advanced Water Ingress Protection
The Explore E2 benefits from full IP69k Certification, the highest possible rating. Also, the rear of the light is protected from in-hull temporary submersion for boats where rough seas and waves sometimes flood the stern.
XFM Removal
The Explore E2 has the same XFM capabilities as the larger lights in the range, being able to remove the light body for maintenance or upgrades, without the need to haul the boat.
Control your Explore E2 lights
Control your Explore E2 lights via the 3rd party switch or push button of your choice.
Features:
- Elliptical 90 / 20 Wide Beam Option
- Circular 20 Beam Option
- Up to 3000 Fixture Lumens
- Compact design and built-in driver.
- Ultra-low profile outer bezel.
- IP69k Certification + In-hull Temporary Submersion Protection
Specifications:
- Fixture Lumens* (total light output from a finished fixture): 3000
- Beam angle (Wide): 90 / 20 Elliptical
- Beam angle (Narrow): 20 Circular
- IP Rating: IP69k
- Minimum-Maximum operating voltage DC: 10-30V DC
- Current / Amp draw (DC): 3.5A@12V DC / 1.5A@24V DC
- Driver type: Internal
- Correlated Color Temp: 6500k (White)
- Rear Temporary Submersion Protection: Yes
- Fish Strobe: Yes
- Anti-fouling properties: Tritonium coated lens
- LED Manufacturer: CREE
Mounting Recommendations:
- Boat size: Up to 20m (65)
- Transom / Hull spacing: 1 - 1.5m (3-5)
- Installation depth below waterline: 25-30cm (10-12)
- Maximum Hull Thickness: 60mm (2.4)
Physical:
- Total weight: 0.8kg (1.76lbs)
- Total Diameter (Including Bezel): 80mm (3.15)
- Diameter Of Body: 59mm (2.32)
- Profile Of Fixture: 3.5mm (0.14)
- Overall Length: 101.5mm (4)
- Minimum Space Required Inside The Hull: 172mm (6.78)
- Hole Cut-Out: 60mm (2.37)
- Material (Mounting Tube / Bezel): AB2 Aluminium Bronze
- Material (Light Body): AB2
- Lens: Glass
- Optics (Wide Beam Option): Hybrid Collimated
- Optics (Narrow Beam Option): Collimated
- CE Approved: Yes
The OceanLED Explore E2 Narrow Beam in Midnight Blue is a compact yet powerful underwater light designed for vessels up to 65 feet. This premium fixture combines advanced engineering with versatile beam options, making it suitable for various aesthetic and functional lighting effects on your boat. The E2 delivers up to 3,000 lumens, ensuring bright, clear illumination beneath the waterline. Its sleek, ultra-low profile outer bezel minimizes drag and visual impact while maintaining durability in harsh marine environments. The integrated driver and compact design simplify installation, making it ideal for tight spaces.
Built with high-quality materials, the Explore E2 features Tritonium coated lenses for anti-fouling properties and CREE LEDs for reliable performance. Its two beam options—a wide elliptical 90 x 20 degrees or a focused 20-degree circular laser beam—allow you to customize your lighting to suit your needs. The elliptical beam provides broad, even illumination, perfect for general aesthetics or visibility, while the narrow beam offers a precise, intense light for highlighting specific features or creating dramatic effects.
Designed for durability, the Explore E2 boasts full IP69k certification, the highest water ingress protection rating, along with rear protection from temporary submersion in rough seas or flooding conditions. This ensures reliable operation even in demanding marine environments. The fixture supports XFM removal, enabling maintenance or upgrades without hauling the boat, and can be controlled via third-party switches or push buttons for seamless integration into your existing control systems.
The Explore E2 is suitable for boats up to 20 meters, with recommended mounting on transoms or hulls spaced 3 to 5 feet apart, installed at a depth of 10 to 12 inches below waterline. Its lightweight construction (less than 1 pound) and minimal space requirements make it an excellent choice for versatile marine lighting solutions. This fixture is CE approved and built with robust AB2 aluminium bronze components, ensuring longevity and corrosion resistance in marine conditions.For detailed installation instructions and maintenance guidance, refer to the OceanLED owner’s manual available online. Enhance your vessel’s underwater aesthetics and safety with the OceanLED Explore E2 Narrow Beam in Midnight Blue, a durable, high-performance lighting solution engineered for marine excellence.
Features:
- Elliptical 90 / 20 Wide Beam Option
- Circular 20 Beam Option
- Up to 3000 Fixture Lumens
- Compact design with built-in driver
- Ultra-low profile outer bezel
- IP69k Certification with in-hull temporary submersion protection
