Explore E2 Wide Beam - Ultra White
The E2 is our latest addition to the Explore range, giving customers a compact smaller XFM light for tight installation spaces, but with all the build quality and premium features of the larger lights in the range.
Choice of Beam
With the E2, you can choose either the signature Explore Series wide-angle beam
(90 x 20 Elliptical), or a new narrow laser beam shape (20 Circular), depending on your desired effect.
Advanced Water Ingress Protection
The Explore E2 benefits from full IP69k Certification, the highest possible rating. Also, the rear of the light is protected from in-hull temporary submersion for boats where rough seas and waves sometimes flood the stern.
XFM Removal
The Explore E2 has the same XFM capabilities as the larger lights in the range, being able to remove the light body for maintenance or upgrades, without the need to haul the boat.
Control your Explore E2 lights
Control your Explore E2 lights via the 3rd party switch or push button of your choice.
Features:
- Elliptical 90 / 20 Wide Beam Option
- Circular 20 Beam Option
- Up to 3000 Fixture Lumens
- Compact design and built-in driver.
- Ultra-low profile outer bezel.
- IP69k Certification + In-hull Temporary Submersion Protection
Specifications:
- Fixture Lumens* (total light output from a finished fixture): 3000
- Beam angle (Wide): 90 / 20 Elliptical
- Beam angle (Narrow): 20 Circular
- IP Rating: IP69k
- Minimum-Maximum operating voltage DC: 10-30V DC
- Current / Amp draw (DC): 3.5A@12V DC / 1.5A@24V DC
- Driver type: Internal
- Correlated Color Temp: 6500k (White)
- Rear Temporary Submersion Protection: Yes
- Fish Strobe: Yes
- Anti-fouling properties: Tritonium coated lens
- LED Manufacturer: CREE
Mounting Recommendations:
- Boat size: Up to 20m (65)
- Transom / Hull spacing: 1 - 1.5m (3-5)
- Installation depth below waterline: 25-30cm (10-12)
- Maximum Hull Thickness: 60mm (2.4)
Physical:
- Total weight: 0.8kg (1.76lbs)
- Total Diameter (Including Bezel): 80mm (3.15)
- Diameter Of Body: 59mm (2.32)
- Profile Of Fixture: 3.5mm (0.14)
- Overall Length: 101.5mm (4)
- Minimum Space Required Inside The Hull: 172mm (6.78)
- Hole Cut-Out: 60mm (2.37)
- Material (Mounting Tube / Bezel): AB2 Aluminium Bronze
- Material (Light Body): AB2
- Lens: Glass
- Optics (Wide Beam Option): Hybrid Collimated
- Optics (Narrow Beam Option): Collimated
- CE Approved: Yes
The OceanLED Explore E2 Wide Beam - Ultra White is a compact yet powerful underwater light designed for marine applications where space is limited. This versatile fixture offers dual beam options, including a signature 90 x 20 elliptical wide-angle beam and a narrow 20 circular laser beam, allowing you to customize your underwater illumination for enhanced visibility and aesthetic appeal. Crafted with premium materials and featuring advanced water ingress protection, the E2 is rated IP69k, ensuring it withstands harsh marine environments, including temporary submersion and high-pressure water jets. Its innovative design incorporates an internal driver and a low-profile outer bezel, making installation straightforward in tight spaces while maintaining a sleek profile.
This light is equipped with CREE LEDs and Tritonium-coated lenses for anti-fouling properties, ensuring durability and longevity in saltwater conditions. The fixture outputs up to 3000 lumens, providing bright, clear illumination that enhances the visual impact of your boat or underwater features. The E2's advanced features include the ability to remove the light body for maintenance or upgrades without removing the entire fixture, thanks to its XFM removal capability. Control options are flexible, allowing operation via third-party switches or push buttons, offering seamless integration into your existing marine electronics system.
Designed for boats up to 65 feet, the OceanLED Explore E2 can be mounted on transoms or hulls with spacing of 3 to 5 feet and requires a minimal installation depth of approximately 10 to 12 inches below the waterline. Its lightweight construction, weighing only around 0.8 pounds, and compact dimensions make it ideal for installation in confined spaces. The fixture’s durable AB2 aluminium bronze body and glass lens ensure long-term performance in marine environments. Whether you need wide coverage or focused illumination, the Explore E2 is an excellent choice for freshwater or saltwater vessels seeking reliable, high-quality underwater lighting.
Features:
- Elliptical 90 / 20 Wide Beam Option for broad illumination
- Circular 20 Beam Option for focused lighting
- Up to 3000 fixture lumens for bright light output
- Compact design with built-in driver for easy installation
- Ultra-low profile outer bezel for streamlined appearance
- IP69k certification with in-hull temporary submersion protection
- XFM removal capability for maintenance and upgrades
- Control compatible with third-party switches or push buttons
- CREE LEDs with Tritonium coated lens for anti-fouling
- Durable AB2 aluminium bronze construction and glass lens
