Actisense Self-Contained Boat Network A2K-SBN-2 for Up to 8 NMEA 2000 Devices

Self-Contained Boat Network - Complete Network f/8 Devices w/Internal Terminators Power Feed

Installing small NMEA 2000 networks is quicker and easier than its ever been with the Self-contained Boat Network (SBN) from Actisense.

The equivalent of eight T-pieces in a single case provides a significant time and space saving with no more connecting multiple T-pieces together. Termination resistors are built in which increases the saving on time and space.

Once the attached 3 meter cable is connected to the boats power supply, an NMEA 2000 network for up to eight devices is ready to use, taking plug play to the next level.

Features:

• Self-contained NMEA 2000 Network


• Integrated Termination Resistors


• 8x NMEA 2000 drops


• Ruggedized, flame retardant over-molded housing


• Metal coupling nuts


• Integrated EMI Shield


• Orange, UL Rated, 3-meter power cable


• Color coded wires, stripped and tinned


• Low cost, quick to install, and provides an easy way to connect multiple NMEA 2000 devices


• Simple installation, fewer components, more reliable, lower cost


• Accommodates the vast majority of compact NMEA 2000 networks


• Suitable for wet and harsh conditions- highly desirable in marine environments


• Reliable, long lasting connections


• Less likely to be susceptible to interference


• UL rated cable provide peace of mind. Color easily differentiates the power cable form drop cables


• Quick installation, no special tools required

Technical Specifications:

Electrical

• Rated Current - 3A


• Rated Voltage - 60 V (AC/DC)


• Internal Termination Resistors - 2 x 120 250mW

Mechanical

• Female Contact - Phosphor bronze, gold plated


• Contact Carrier - PA66 (30% Glass filled), black


• Contact Polarization - Standard M12 A polarization


• Mating Thread - M12


• Screw Cap - Brass, nickel plated


• O-Ring Seal - Rubber, black


• Housing - TPU (Halogen Free) over Epoxy filled PBT housing


• Flammability rating - UL94 V-0


• Internal Housing Shield - Copper foil


• Cable Jacket Material - 0.8mm Nom. PVC, orange


• Cable Outer Diameter - 6.8mm


• Cable Length - 3m


• Wire Length - 150mm (10mm stripped and tinned)


• Wire Jacket - PVC, Red Black


• Wires - 16 AWG (stripped and tinned)


• Drain - 18 AWG (34 strand tinned copper)


• Cable Shield - Al-mylar


• Weight - 410g

Approvals and Certifications

• Protection - IP67 (when mated)


• Operating Temperature - -25C to +70C


• Storage Temperature - -40C to +85C

The Actisense A2K-SBN-2 is a comprehensive, self-contained NMEA 2000 network solution designed specifically for marine environments. This compact unit consolidates the functionality of eight T-pieces into a single rugged case, significantly simplifying installation and saving valuable space aboard your vessel. Its integrated termination resistors ensure reliable data transmission, reducing the need for additional components and minimizing potential points of failure. Once connected to a 3-meter power cable, the network is ready to support up to eight NMEA 2000 devices, enabling plug-and-play connectivity for marine electronics without complex wiring setups. The durable, flame-retardant over-molded housing, coupled with metal coupling nuts and an integrated EMI shield, ensures longevity and resistance to harsh marine conditions, including exposure to moisture and interference. The orange UL-rated power cable, with color-coded, stripped, and tinned wires, facilitates quick and error-free installation, with no special tools required. Designed to meet rigorous industry standards, the network supports currents up to 3A and voltages up to 60V AC/DC, with internal 120Ω termination resistors enhancing signal stability. Mechanical features include gold-plated phosphor bronze contacts, a robust M12 mating thread, and a rubber O-ring seal to prevent water ingress. The entire assembly is rated to operate reliably across a wide temperature range from -25°C to +70°C, making it suitable for the demanding conditions found at sea. Certified with IP67 protection when mated, this network offers a dependable, low-cost solution for marine electronics integration. Whether installing new systems or upgrading existing networks, the Actisense A2K-SBN-2 provides a straightforward, reliable, and long-lasting means to connect multiple NMEA 2000 devices efficiently. For detailed installation and operational guidance, please refer to the official manual available online.

Features:

• Self-contained NMEA 2000 network with integrated termination resistors

• Supports up to 8 NMEA 2000 device drops

• Rugged, flame-retardant over-molded housing suitable for marine use

• Metal coupling nuts for secure connections

• Built-in EMI shield for interference reduction

• Includes 3-meter UL-rated, orange power cable with color-coded, stripped, and tinned wires

• Easy, tool-free installation with fewer components

• Designed to withstand wet, harsh marine environments

• Rated for 3A current and 60V voltage operation

• Mechanical features include gold-plated contacts, M12 threading, and rubber O-ring seals

• Certified IP67 protection when mated, operational from -25°C to +70°C
