B&G Triton Digital Display Part Number 000-13294-001 - Multi-Purpose Sailing Instrument with 4.1-inch Color LCD

Triton Digital Display

Multi-purpose sailing instrument and autopilot display with a 4.1 color screen, optically bonded for zero condensation and featuring trans-flective LCD technology for exceptional contrast and visibility in all lighting conditions. 8mm mounting height matches other BG MFDs and system component.

The full-colour Triton Display provides sailors with a clear visual representation of key instrument data including Speed, Depth, Wind, Heading, AIS targets, GPS data and more.

An Optically Bonded display means absolutely zero condensation or fogging, while transflective LCD technology provides exceptional contrast and visibility - day or night - while consuming less power than traditional backlight-only displays. The flexible, NMEA 2000 certified, Triton Display can be integrated into a wider navigation system and also be combined with a Triton Pilot keypad and NAC autopilot computer to create a complete autopilot control system, featuring BG sail-specific autopilot steering algorithms.

Features:

• Optical Bonding Sporting an Optically Bonded 4.1 LCD display, Triton allows you to see clearly in all conditions with its large clear color display 100% free from condensation or fogging


• Efficient LCD Technology: Transflective LCD technology uses reflected ambient light to enhance day-time visibility, providing the clearest sailing dedicated display available. LED backlighting provides highly adjustable illumination when required, making Triton exceptionally efficient and extending time available from your battery capacity


• Easy to Use: Triton provides simple on-screen menus controlled by soft-touch and reliable waterproof buttons


• Intuitive design makes it easy to configure and use your display




• Low Profile Design: At just 8mm thin the Triton instrument adds a sleek look to any boat


• Nearly half the dimension of its thick competitors, Triton wont get in the way, catch ropes or offend the eye!




• NMEA 2000 Certified: NMEA 2000 certification means you can be confident when adding Triton to an existing NMEA 2000 system. NMEA 2000 certification also opens up a wide variety of future expansion options for your Triton system


• Easy Installation: A straight-forward front mounting method and a clip-on bezel over the (4) mounting screws combine with a single NMEA 2000 connection carrying both power and networked data




• Autopilot Integration: Triton will display BG Pilot data on a clear status screen

Specifications:

• Dimensions: 118 x 115 x 28mm (4.6 x 4.5 x 1.1)


• Weight: 0.32 kg (0.7 lbs)




• Power Consumption: 1.8 Watts (MAX)


• Network Load: 3 LEN




• Color: Black


• Display Size: 4.1 (diagonal). 4:3 Aspect ratio




• Display Type: Transmissive TFT-LCD, bonded. White LED backlight


• Dsiplay Resolution: 320 x 240 pixels




• Illumination: White for day mode. Red, green, blue or white for night mode


• Environmental Protection, Waterproof: IPx7




• Environmental Protection, Humidity: up to 95% RH


• Compass Safe Distance: 300mm (1.0)




• Temperature Operating: -15 to +55C (5F to +131F)


• Temperature Storage: -30 to +70C (-22 to +158F)

The B&G Triton Digital Display is a versatile sailing instrument and autopilot display designed to enhance navigation and system integration on your vessel. Featuring a 4.1-inch full-color bonded LCD, it offers exceptional contrast and visibility in all lighting conditions, thanks to its optically bonded construction and transflective LCD technology. This means zero condensation or fogging, ensuring a clear view whether you're sailing in bright sunlight or at night. Its efficient power consumption and slim profile make it an ideal addition without compromising your boat's aesthetics or battery life. The display's simple on-screen menus and waterproof soft-touch buttons facilitate easy operation, allowing quick access to vital data such as speed, depth, wind, heading, AIS targets, and GPS information. Designed for straightforward installation, it supports a front mounting method with a clip-on bezel and a single NMEA 2000 connection that manages both power and data, simplifying system setup and expansion. The Triton display's NMEA 2000 certification guarantees compatibility with existing systems and future upgrades, offering peace of mind for long-term use. Its autopilot integration displays BG Pilot data clearly on a dedicated status screen, enabling seamless control and navigation management. Built to withstand harsh marine environments, it features an IPx7 waterproof rating and can operate in humidity levels up to 95% RH, with temperature ranges suitable for most climates. Whether used as a standalone instrument or part of a comprehensive navigation system, the B&G Triton Digital Display is a reliable, efficient, and sleek solution for sailors seeking high-quality visual data and autopilot control in a compact form factor.

Features:

• Optical Bonding: Features a 4.1-inch bonded LCD display for clear visibility in all conditions, free from condensation or fogging

• Efficient LCD Technology: Transflective LCD uses ambient light for daytime clarity, with adjustable LED backlighting to optimize power consumption

• User-Friendly Interface: Simple on-screen menus controlled by soft-touch and waterproof buttons for easy operation

• Low Profile Design: At just 8mm thick, the Triton offers a sleek, unobtrusive appearance that won't interfere with sailing or catch ropes

• NMEA 2000 Certified: Ensures compatibility with existing marine systems and allows for future expansion

• Easy Installation: Front mounting with a clip-on bezel and a single NMEA 2000 connection simplifies setup and integration

• Autopilot Integration: Displays BG Pilot data on a dedicated status screen for seamless autopilot control in conjunction with NAC autopilot systems

• Durable Construction: Waterproof to IPx7 standards and capable of operating in high humidity environments, suitable for diverse marine conditions
