Fusion Apollo Marine 4 Channel 1200-Watt Amplifier - High Power Marine Audio Solution

Apollo Marine 4 Channel 1200-Watt Amplifier

This 4-channel amplifier with 150-watt RMS per channel can power up to four pairs of speakers or two pairs of speakers and one subwoofer. It includes high-power mode adapters for simple bridging to increase power.

Features:

• Keep the music going for longer without draining your battery as quickly


• No more manual adjustments to your audio settings. The Easy Tune feature does it for you


• A glance at the LED indicators lets you identify if the amplifiers have a short or if theyre overheating


• Less distortion and noise, so you enjoy quality audio


• Mounting brackets are included for simple installation


• Dont worry about potential overheating damage with our ignition protection design

Power Efficiency

The Apollo amplifiers are designed to produce impressive power with less drain on your battery. This amp produces 150-watt RMS per channel.

Easy Tune Feature

These amplifiers use the Easy Tune feature, which automatically regulates audio settings. So, users can get the best quality sound without making manual adjustments.

Less Distortion

Some amplifiers distort audio when they add power. Fusions are specifically designed with minimal distortion and noise, so you can enjoy high-quality audio, even at higher volumes.

LED Indicators

Identify electrical issues at a glance. These indicator lights will show you issues with electrical currents and shorts, as well as temperature.

Mounting Brackets

Easily install the amplifiers on board with the included mounting brackets.

Ignition Protected

The ignition-protected design helps prevent potential damage from overheating.

Conformal-Coated PCBS

The amplifiers circuit board has been specially coated to provide extra protection from the marine elements.

2 OHM Stable

Connect up to two speakers per channel, increasing setup options.

Fusion True-Marine Design

The amplifier is designed to last season after season. They have been tested to a high level of protection against salt fog, temperature, vibration, and UV.

In the Box:

• One Apollo 4-channel amplifier


• One mounting bracket


• One power connector


• Two speaker connectors with high-power mode adapters


• Four 8-gauge, flat-head self-tapping screws


• Four 8-gauge, pan-head self-tapping screws (for mounting bracket)


• Four screw covers


• Fuse holder


• Mounting template


• Installation instructions


• ISPI

Specifications:

• Physical Dimensions without Bracket (L x W x H): 9.25" x 7.06" x 1.75" (235 x 180 x 45 mm)


• Physical Dimensions with Bracket (L x W x H): 9.25" x 7.06" x 2.13" (235 x 180 x 50 mm)


• Weight: 4.85 lb (2.2 kg)


• Water Rating: IPX2


• Amplifier Class: Class-D


• CEA-2006 Power Rating: 150 watt RMS x 4 @ 14.4 V input - 4 ohm < 1% THD


• Total Rated Power Output, 2 Ohm (Watts): 290 watt RMS x 4 @ 14.4 V input - 2 ohm < 1% THD


• Total Rated Power Output, 4 ohm Bridged (watts): 580 watt RMS x 2 @ 14.4 V input - 4 ohm Bridged < 1% THD


• Peak Power (watts): 1200 watts


• Input Sensitivity: 1.6 V RMS


• Input Impedance: 22k ohm


• Operating Voltage: 10.8 V - 16 V DC


• Current Draw, in Standby/off Using Amplifier on Wire: < 5 mA @ 14.4 V input


• Current Draw, On, No Audio: < 1.15 A @ 14.4 V input


• Fuse Rating: 85 A electronic fuse (no replacement necessary)


• Power-Cable Fuse Model and Rating: Bussmann BK/AMI-030 30 A fast-acting


• Ignition Safety Protected (SAE J1171): Yes


• Protection Circuits: Reverse voltage, input under/over voltage, over temperature, and output short circuit


• Operating temperature range: 32 to 122 F (0 to 50 C)


• Warranty: 3 years

The Fusion Apollo Marine 4 Channel 1200-Watt Amplifier (Part Number: 010-02284-45) is engineered to deliver robust, high-quality sound in marine environments. Designed with durability and performance in mind, this amplifier provides 150-watt RMS per channel, capable of powering multiple speakers or a combination of speakers and a subwoofer. Its Class-D design ensures efficient power usage, reducing battery drain during extended use. The amplifier’s conformally-coated PCBs and IPX2 water rating make it well-suited for marine applications, resisting salt fog, temperature fluctuations, vibration, and UV exposure. It also features a mounting bracket and installation hardware for easy setup on boats, ensuring secure placement even in rough conditions.
The Apollo amplifier includes advanced features such as the Easy Tune system, which automatically calibrates audio settings to optimize sound quality, eliminating the need for manual adjustments. LED indicators provide real-time feedback on electrical issues like shorts or overheating, simplifying troubleshooting. Its ignition protection design further guards against potential damage from heat buildup, promoting longevity and reliable operation in demanding environments.
With a total rated power output of 580 watts when bridged at 4 ohms and 290 watts per channel at 2 ohms, this amplifier offers versatile setup options. Its stability at 2 ohms allows connecting up to two speakers per channel, providing flexibility in configuration. The amplifier’s minimal distortion and noise ensure clean, clear audio, even at high volumes, enhancing your marine audio experience. The package includes all necessary mounting hardware, a fuse holder, and a detailed installation guide to facilitate straightforward installation.
Built to last season after season, the Fusion Apollo Marine amplifier combines advanced protection circuits, a durable design, and efficient power delivery to meet the demands of marine environments. Whether you're upgrading your boat's sound system or installing a new setup, this amplifier offers professional-grade performance with reliable, long-term operation.

Features:

• 150-watt RMS power per channel for powerful marine audio

• Class-D amplifier design for high efficiency and low battery drain

• Conformal-coated PCBs resist salt, moisture, and corrosion

• IPX2 water rating suitable for marine environments

• Easy Tune feature automatically calibrates audio settings

• LED indicators for quick troubleshooting of shorts and overheating

• Ignition protection design prevents damage from heat

• Includes mounting bracket and hardware for simple installation

• Stable at 2 ohms for flexible speaker configurations

• Minimal distortion and noise for high-quality sound reproduction

• High-rated fuse and protection circuits ensure reliable operation

• Designed to withstand salt fog, temperature fluctuations, vibration, and UV exposure

• Compact dimensions make it suitable for tight installation spaces

• Three-year warranty for peace of mind
