APK 10 Autopilot Keyboard - Horizontal
GAIN PRECISE CONTROL OF YOUR AUTOPILOT
Get easy-to-use control of your Reactor 40 autopilot, and put simple, intuitive knob and button activation, heading changes, and more at your fingertips.
Rotary Knob
The LED-encircled knob provides precise heading control and colored reference of autopilot status.
Autopilot Buttons
Dedicated engage and standby buttons make starting and stopping your autopilot easy.
Multipurpose Buttons
Add more autopilot control functions based on your vessel type and setup preferences.
Simple Installation
Connect to your NMEA 2000 network with a single port and cable for integration and power.
Compact Design
A low-profile design matches the height of your GHC 50 instrument and GPSMAP chartplotter. The APK 10 keypad accessory comes in horizontal and vertical mounting options to suit your new or existing helm.
In The Box:
- APK 10 autopilot keypad (horizontal)
- Backbone/drop cable (2 m) and T-connector for the NMEA 2000Network
- Mounting hardware (flushand surface)
- Documentation
Specifications:
- Dimensions (WxHxD): Flush mount: 5.5 x 2.3 x 0.28 (139.7 x 57.4 x 7.0 mm) Surface mount: 5.5 x 2.3 x 0.65 (140.7 x 58.4 x 16.4 mm)
- Weight: Horizontal: 4.09 oz (116 g)
- Temperature range: From 5 to 158F (from -15 to 70C)
- Material: Fully-gasketed, high-impact plastic
- Water rating: IPX7
- Compass-safe distance: 4.5 (114 mm)
- Powered input: Powered supplied from the NMEA 2000 network
The Garmin APK 10 Autopilot Keyboard offers precise and intuitive control of your Reactor 40 autopilot system. Designed with ease of use in mind, this horizontal control panel features a rotary knob encircled with LED lighting, providing accurate heading adjustments and real-time status indicators through colored feedback. Dedicated engage and standby buttons simplify starting and stopping your autopilot, while multipurpose buttons allow for customization based on your vessel's setup and control preferences. Connecting seamlessly to your NMEA 2000 network via a single port and cable, the APK 10 allows for straightforward installation with minimal effort, making it suitable for both new and existing helm configurations. Its low-profile, compact design matches the height of Garmin’s GHC 50 instrument and GPSMAP chartplotters, and the horizontal mounting option integrates smoothly into your helm space. Crafted from fully-gasketed, high-impact plastic, the control panel is rated IPX7 for water resistance and features a compass-safe distance of 4.5 inches, ensuring reliable operation in demanding marine environments. The device is powered directly from your NMEA 2000 network, eliminating the need for additional wiring or power sources. In the package, you will find the APK 10 autopilot keypad, a 2-meter backbone/drop cable with T-connector, mounting hardware for flush and surface mounting, and comprehensive documentation to facilitate quick setup. Whether you need a dedicated autopilot control solution for your vessel or a reliable upgrade, the Garmin APK 10 offers professional-grade control with simple installation and robust durability, all in a sleek, space-saving design.
Features:
- Rotary Knob: LED-encircled for precise heading control and status indication
- Autopilot Buttons: Dedicated engage and standby buttons for easy operation
- Multipurpose Buttons: Customizable controls tailored to vessel setup
- Simple Installation: Connects via a single NMEA 2000 port and cable for quick setup
- Compact Design: Low-profile, matches Garmin GHC 50 instruments and GPSMAP chartplotters
- Water Resistance: IPX7 rated for reliable operation in harsh marine conditions
- Material: Fully-gasketed, high-impact plastic construction
- Power Supply: Draws power directly from NMEA 2000 network
