HEISE LED Lighting Systems HE-DR14 Dual Row 14-Inch LED Light Bar for Off-Road & Work Vehicles

Dual Row LED Light Bar - 14"

SPECS

• Input Voltage: 10-30V DC


• Power Consumption: 72W


• (24-3W CREE LEDs)


• Raw Lumens: 5760


• LUX @ 10M: 466


• Color Temperature: 6000K


• Beam Pattern: Combo/Flood(90)/Spot(8)

CONSTRUCTION

• Housing Material: Die-cast Aluminum Housing


• Housing Color: Black


• Lens Material: PC


• Mounting Bracket: Die-cast Aluminum


• Length of Bar without Mounting Brackets: 14"


• Hole Dimensions:

• Brackets turned inward - 13.50"


• Brackets turned outward - 14.75"


• Mounting Bolt Drill - .25"

• Height of Light Bar Itself: 3"


• Depth of Light Bar Itself: 3.50"


• Electronics: Integrated-Epoxy Encapsulated


• Hardware: Stainless 316

OPERATION

• Operating Temperature: -40C to +60C


• Current Consumption: 3.7 amps @ 13.8 volts


• IP Rating: IP68


• Protections: Reverse Polarity

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The HEISE LED Lighting Systems HE-DR14 dual row 14-inch LED light bar offers powerful illumination for off-road, work, and utility vehicles. Featuring 24 high-efficiency CREE LEDs with a combined power consumption of 72W, this light bar produces up to 5,760 raw lumens and provides a versatile beam pattern including combo, flood, and spot options. With a color temperature of 6000K, it ensures bright, clear visibility in various conditions. The durable die-cast aluminum housing, finished in black, provides excellent heat dissipation and weather resistance. The polycarbonate lens offers impact resistance, while the integrated epoxy-encapsulated electronics enhance reliability. Designed for demanding environments, the light bar operates effectively within temperatures from -40°C to +60°C and features an IP68 rating for water and dust resistance. The stainless steel 316 hardware and mounting brackets ensure secure installation and long-term durability. Perfect for trucks, SUVs, and utility vehicles, this LED light bar enhances safety and visibility during night driving or work tasks. Easy to install with a 0.25-inch mounting bolt drill, the HE-DR14 is a reliable addition to any vehicle needing high-intensity lighting. Note: This product contains chemicals known to the State of California to cause cancer and reproductive harm; for details, visit P65Warnings.ca.gov.

Features:

• Input Voltage: 10-30V DC for versatile vehicle compatibility

• Power Consumption: 72W for efficient operation

• LED Configuration: 24 high-performance 3W CREE LEDs

• Luminous Output: 5760 raw lumens for bright illumination

• Beam Pattern: Combo with flood (90°) and spot (8°) options

• Housing Material: Die-cast aluminum for durability and heat dissipation

• Lens Material: Polycarbonate for impact resistance

• Mounting Hardware: Stainless steel 316 for corrosion resistance

• Operating Temperature Range: -40°C to +60°C for reliable use in extreme conditions

• Water and Dust Resistance: IP68 rated for harsh environments

• Electrical Protections: Reverse polarity protection for safe operation
