Hella Marine Slim Line LED Warm White Courtesy Lamp with Stainless Steel Bezel - 12V

Slim Line LED 'Enhanced Brightness' Round Courtesy Lamp - Warm White LED - Stainless Steel Bezel - 12V

Attractive, energy efficient lighting for interior and exterior use.

Hella Marine round LED courtesy lamps can be installed almost anywhere on board.

Over 3 x brighter than regular Soft Light White and Warm White LED courtesy lamps.

Advanced lens technology provides a cool and even spread of soft light without glare or eye strain. Hella Marine LED courtesy lamps consume a fraction of the energy of traditional bulb lamps and run very cool due to their low current draw of less than 0.5W (less than 0.04A @ 12V). This provides safer installation into light weight materials where the heat of incandescent lamps may cause damage to the surrounding structure.

Each lamp is completely sealed, highly shock, impact and vibration resistant, perfectly suited for the demanding marine environment.

Enhanced brightness lamps include a surface mounting ring with 3 x stainless steel screws. Stainless steel and white rim lamps include a white spacer, black rim lamps a black spacer.

Specifications:

• Lens Material: UV resistant enhanced impact acrylic


• Rim Material: UV resistant plastic. 316 stainless steel


• Dimming: Dimmed via Hella Marine Dimmer 5XA 998 572-001


• Cable: Pre-wired with 120mm of single core marine cable


• Operating Voltage: 12V DC or 24V DC


• Power Consumption: < 0.5W ( < 0.042A @ 12V / < 0.02A @ 24V )


• Degree of Protection: IP 67 - Completely Sealed


• Mounting: Stainless steel screws included


• Weight: 50g (including cable)

The Hella Marine Slim Line LED Courtesy Lamp offers an energy-efficient solution for interior and exterior lighting on boats and marine vessels. Featuring a sleek round design with a stainless steel bezel, this lamp provides a warm white light that is over three times brighter than standard soft white LED courtesy lamps. Its advanced lens technology ensures a cool, even spread of soft light without glare or eye strain, making it suitable for various marine applications. The lamp consumes less than 0.5W of power at 12V and less than 0.02A at 24V, significantly reducing energy consumption compared to traditional incandescent lamps. The low current draw allows for safer installation in lightweight materials, as it minimizes heat generation that could potentially damage surrounding structures. The fully sealed construction makes the lamp highly resistant to shock, impact, and vibration, ensuring reliable operation in demanding marine environments. Its UV-resistant impact acrylic lens and UV-resistant plastic rim enhance durability, while stainless steel screws facilitate easy mounting. The lamp is pre-wired with a 4-inch marine cable for straightforward installation and is compatible with dimming via the Hella Marine Dimmer 5XA. Its IP67 rating guarantees complete sealing against water and dust, making it an ideal choice for harsh conditions on boats or yachts. Whether used for courtesy lighting or accent illumination, this lamp combines durability, efficiency, and style to meet the rigors of marine use. The lightweight design at approximately 1.6 ounces further simplifies installation and integration into existing lighting systems.

Features:

• Energy-efficient warm white LED with enhanced brightness for better visibility

• Advanced lens technology provides a cool, even light spread without glare

• Low power consumption: less than 0.5W at 12V and 0.02A at 24V

• Constructed with UV-resistant impact acrylic lens and stainless steel bezel

• Fully sealed IP67 rating for water and dust resistance

• Pre-wired with 4-inch marine cable for easy installation

• Compatible with dimming systems when used with Hella Marine Dimmer 5XA

• Shock, impact, and vibration resistant, suitable for demanding marine environments

• Includes stainless steel mounting screws and spacers for versatile mounting options

• Lightweight at approximately 1.6 ounces for straightforward integration
