Lowrance B60-12 Tilted Element Transducer - 12 Inch Bronze Depth and Temperature Sensor for 8-15 Degree Deadrise Boats

B60 Tilted Element 12

12 tilted version is designed for 8 - 15 deadrise angles

The bronze B60-12 provide a vertical beam without a fairing. Inside the housing, the ceramic element is tilted to provide built-in deadrise compensation. The resulting vertical beam provides excellent echo returns for more accurate depth readings. The nearly flush housing minimizes drag with only 5 mm (3/16") extending outside of the hull.

Features:

• Depth/Temp




• 50/200 kHz




• 600w RMS




• Mid-performance




• Bronze

The Lowrance B60-12 Tilted Element Transducer is engineered to deliver precise depth and temperature readings for boats with deadrise angles between 8 and 15 degrees. Its 12-inch bronze housing provides durability and optimal performance in various marine conditions. The ceramic element inside the housing is specifically tilted to compensate for the boat's deadrise angle, resulting in a vertical beam that ensures accurate echo returns and reliable depth measurements. The design features a nearly flush housing with only 3/16 inches (5 mm) protruding outside the hull, minimizing drag and maintaining vessel efficiency. This mid-performance transducer operates at 50/200 kHz with a power output of 600 watts RMS, making it suitable for recreational and semi-professional boating applications. The bronze construction enhances corrosion resistance, ensuring longevity in harsh marine environments. Easy to install and maintain, the B60-12 is ideal for anglers, boaters, and marine enthusiasts seeking dependable depth and temperature data. For detailed installation instructions and maintenance guidelines, refer to the owner’s manual available online. Please note that this product may not be returned to the original point of purchase; contact Lowrance directly for support with any issues or concerns.

Features:

• Depth and temperature measurement for reliable marine data

• Operates at 50/200 kHz for versatile sonar performance

• 600 watts RMS power output for mid-range performance

• Bronze housing offers corrosion resistance

• Designed for boats with 8 to 15-degree deadrise angles

• Tilted ceramic element provides built-in deadrise compensation

• Nearly flush mounting minimizes drag and hull impact
