Lumishore SUPRA TIX804 Interchangeable Thru-Hull Lighting System

SUPRA TIX804 Interchangeable Thru-Hull

The TIX804 produces an incredible 13,500 fixture lumens and an ultra-wide 110 beam angle to achieve a beautiful halo of light around the yacht. The best choice for those who want full power dual-colored lights without sacrificing brightness!

Available in blue and white. You can easily switch between colors, fade colors, adjust brightness, and strobe at two speeds.

The TIX804 is controlled by the SUPRA i-Connect Hub Switch, or directly from your compatible MFD and/or optional Lumishore Display, when you add the SUPRA Bridge Module.

TIX models have the added benefit of an internal LED array and integrated driver, for the ability to service from inside the hull and to simplify installation.

Suitable for transom, side, and bottom mounting.

Specifications:

• Available Colors: Dual Color (Blue White)


• Lumens: 30,375


• Fixture Lumens (White): 13,500


• Number Type Of LED: White - 36 x 10W, Blue - 48 x 3W


• LED Power - HICOB Array: Yes


• Typical LED Life: 50,000+ Hours


• Warranty: 3 Years


• User Control Options: SUPRA i-Connect Hub Switch Certifi ed MFD Screen* EOS-LUX-SUPRA Display WiFi control from Smart phone or Connected Device (via MFD or local WiFi Network)*

* Requires SUPRA Bridge Module

The Lumishore SUPRA TIX804 Interchangeable Thru-Hull provides powerful illumination with a light output of 13,500 fixture lumens and an ultra-wide 110-degree beam angle, creating a stunning halo effect around your yacht. Designed for versatility and ease of use, this lighting system offers dual-color options in blue and white, allowing you to switch colors, fade between them, and adjust brightness or strobe at two different speeds for customized ambiance. The TIX804 is compatible with the SUPRA i-Connect Hub switch and can be controlled directly from your compatible MFD or optional Lumishore Display when combined with the SUPRA Bridge Module, providing seamless integration with your existing onboard control systems. Its internal LED array and integrated driver simplify installation and facilitate servicing from inside the hull, reducing maintenance time and effort. Suitable for transom, side, and bottom mounting, the TIX804 is ideal for enhancing both the aesthetic and functional aspects of your vessel’s lighting setup. With a robust LED lifespan exceeding 50,000 hours, this fixture is backed by a three-year warranty, ensuring long-term performance and reliability. The fixture features 36 high-power 10W white LEDs and 48 3W blue LEDs, delivering a total lumen output of 30,375 for bright, vivid illumination. Additional features include an HICOB LED array for enhanced efficiency and durability, and user control options via the SUPRA i-Connect Hub, MFD-certified screens, WiFi control through the Lumishore EOS-LUX-SUPRA display, or connected devices over local WiFi networks. Designed with ease of installation and operation in mind, the Lumishore SUPRA TIX804 is an excellent choice for boat owners seeking powerful, customizable underwater lighting with advanced control capabilities.

Features:

• Powerful illumination with 13,500 fixture lumens and 110-degree beam angle

• Dual-color options in blue and white with easy switching and fading capabilities

• Adjustable brightness and strobe effects at two speeds

• Controlled via SUPRA i-Connect Hub switch, MFD, or Lumishore Display with optional Bridge Module

• Internal LED array and integrated driver for simplified installation and servicing

• Suitable for transom, side, and bottom mounting

• Long-lasting LEDs with a lifespan of over 50,000 hours

• Robust construction backed by a 3-year warranty

• High-power white (36 x 10W) and blue (48 x 3W) LEDs for vivid lighting

• Additional control options include WiFi connectivity and smart device integration
