Pacer TDT04F-2RP Deutsch Receptacle Repair Kit for 14-18 AWG Wire, 2-Position

DT Deutsch Receptacle Repair Kit - 14-18 AWG (2 Position)

Pacer's DT repair kits use the larger size 16 contacts (Deutsch Pin P/N 0460-215-16141, Socket P/N 0462-209-16141) for applications using 14 AWG wire. However, DT series connectors are designed for 18-14 wire gauge applications. The DT series offers electrical designers the ability to use multiple sizes of 16 contacts (18-14 AWG) each with a 13-amp continuous capacity, within a single shell. Pacer also sells these other components for use in a wider range of applications.

Features:

• Packs include all parts needed to assemble a connector


• One to two extra terminals


• Cavity plugs to seal open circuits

Applications:

• Wire-to-wire applications


• Enclosed connectors offer field-proven reliability and rugged quality

Compliances:

• Ingress Protection (IP) Level: IP68 and IP6K9K


• EU RoHS/ELV


• Standard UL-94 Recognized

Characteristics:

• Wedge locks ensure contact alignment and retention


• Redundant Silicone Seals


• Hand-insertable and removable contacts

Technical Specifications:

• Number of Cavities: 2


• Housing: Rectangular receptacle, plastic reinforced with glass fiber


• Contact Size: 16 (13 amp)


• Wire Size: 14 AWG


• Holds Pin/Socket: Pins


• Operating Temperature: -55C to 125C

Contents:

• (1) 2 pos. receptacle


• (1) 2 pos. wedge lock


• (3) pins

The Pacer TDT04F-2RP Deutsch Receptacle Repair Kit is designed for efficient and reliable wire-to-wire connections in applications requiring 14 to 18 AWG wire sizes. This kit includes all necessary components to assemble a durable connector, including a 2-position rectangular plastic housing reinforced with glass fiber, two wedge locks for secure contact retention, and three removable pins. The design ensures easy hand-insertion and removal of contacts, facilitating field repairs and maintenance. The kit's contacts are rated for 13 amps, making it suitable for various demanding electrical applications. The inclusion of cavity plugs helps seal open circuits, protecting against environmental contaminants and ensuring consistent performance. The rugged construction and field-proven reliability make this kit ideal for use in harsh environments, with an ingress protection rating of IP68/IP6K9K and compliance with EU RoHS/ELV standards. Operating temperatures range from -55°C to 125°C, allowing it to perform in extreme conditions. The use of wedge locks guarantees proper contact alignment, while redundant silicone seals provide additional environmental sealing, safeguarding electrical connections from moisture and dust. Whether used in industrial machinery, automotive systems, or other demanding fields, this repair kit offers a practical solution for maintaining high-quality connections and extending the lifespan of Deutsch connectors. The kit's compact design and comprehensive contents make it an essential tool for technicians requiring reliable wire repair options in the field.

Features:

• Includes all parts needed to assemble a 2-position Deutsch receptacle connector

• Contains extra terminals for replacement or additional use

• Provides cavity plugs to seal open circuits for environmental protection

• Wedge locks ensure proper contact alignment and secure retention

• Redundant silicone seals enhance environmental sealing

• Hand-insertable and removable contacts facilitate easy installation and repair

• Constructed with a rugged, reinforced plastic housing for durability

• Rated for 13 amps and compatible with 14-18 AWG wire sizes

• Designed for wire-to-wire applications in harsh environments

• Compliance with IP68/IP6K9K ingress protection standards and EU RoHS/ELV
