Pacer TDT06F-8RS Deutsch Plug Repair Kit for 14-18 AWG Wire, 8 Positions

DT Deutsch Plug Repair Kit - 14-18 AWG (8 Position)

Pacer's DT repair kits use the larger size 16 contacts (Deutsch Pin P/N 0460-215-16141, Socket P/N 0462-209-16141) for applications using 14 AWG wires. However, DT series connectors are designed for 20-14 wire gauge applications. The DT series offers electrical designers the ability to use multiple sizes of 16 contacts (20-14 AWG) each with a 13-amp continuous capacity, within a single shell. Pacer also sells these other components for use in a wider range of applications.

Features:

• Packs include all parts needed to assemble a connector


• One to two extra terminals


• Cavity plugs to seal open circuits


• Applications:


• Wire-to-wire applications


• Enclosed connectors offer field-proven reliability and rugged quality

Compliances:

• Ingress Protection (IP) Level: IP68 and IP6K9K


• EU RoHS/ELV


• Standard UL-94 Recognized

Characteristics:

• Wedge locks ensure contact alignment and retention


• Redundant Silicone Seals


• Hand-insertable and removable contacts

Technical Specifications:

• Number of Cavities: 8


• Housing: Rectangular receptacle, plastic reinforced with glass fiber


• Contact Size: 16 (13 amp)


• Wire Size: 14 AWG


• Holds Pin/Socket: Sockets


• Operating Temperature: -55C to 125C

Contents:

• (1) 8 pos. plug


• (1) 8 pos. wedge lock


• (10) sockets


• (4) cavity plugs

The Pacer TDT06F-8RS Deutsch Plug Repair Kit is a comprehensive solution designed for reliable wire-to-wire connections in various electrical applications. This kit is suitable for use with 14 to 18 AWG wires and features an 8-position rectangular receptacle housing that is reinforced with durable glass fiber. The kit includes all necessary parts to assemble a secure and protected connector, such as sockets, cavity plugs, and wedge locks to ensure proper contact alignment and retention. These components are hand-insertable and removable, facilitating easy installation and maintenance in the field. The design incorporates redundant silicone seals and wedge locks to provide field-proven reliability and rugged durability, making it ideal for demanding environments. The connectors meet stringent standards, with an ingress protection level of IP68 and IP6K9K, ensuring protection against dust and water ingress, and are compliant with EU RoHS/ELV directives. The parts are UL-94 recognized, affirming safety and flame resistance. This repair kit is engineered to operate efficiently within a temperature range from -55°C to 125°C, supporting a wide array of industrial and automotive applications. The kit includes one 8-position plug, one wedge lock, ten sockets, and four cavity plugs, providing everything needed for a complete repair or assembly. Whether used for wire-to-wire connections or in enclosed, rugged environments, the Pacer Deutsch Plug Repair Kit offers a dependable, high-quality solution for electrical system integrity.

Features:

• Includes all parts needed to assemble a connector

• Provides one to two extra terminals for flexibility

• Cavity plugs seal open circuits for protection

• Suitable for wire-to-wire applications

• Enclosed connectors deliver field-proven reliability and rugged quality

• Ingress Protection (IP) Level: IP68 and IP6K9K for water and dust resistance

• EU RoHS/ELV compliant for environmental safety

• Standard UL-94 flame-resistant recognition

• Wedge locks ensure contact alignment and retention

• Redundant silicone seals for enhanced sealing performance

• Contacts are hand-insertable and removable for ease of maintenance

• Housing made of plastic reinforced with glass fiber for durability

• Operates effectively from -55°C to 125°C
