RAM Mounting Systems RAM-B-174-UN4U Universal Finger Grip Holder for Brake and Clutch Reservoirs

RAM Universal Finger Grip Holder Brake/Clutch Reservoir Mount
Part #: RAM-B-184-UN4U

The base consists of a 1" diameter rubber ball, hardware for mounting to both brake/clutch reservoirs and rails that are 0.5" to 1.25" in diameter. The mounting hardware for brake/clutch reservoirs include both standard and metric mounting bolts. Multiple pivot points, rubber ball and socket technology allows for almost infinite adjustment and perfect viewing angles. High quality materials insure your device is safe, secure, and within easy reach.

The RAM Composite Universal Finger Grip Holder is designed to hold a large amount of cell phones and electronic devices. The holder comes with (3 sets) of four flexible rubber coated fingers placed along sides to grip your device. The fingers open by squeezing the ends to open the small finger arms. The bottom of the holder includes a back plate that adds support to the device being held by the mount.

This mount is designed to hold the following devices:
Cell Phones
2-Way Radios
GPS Devices

Height Dimensions:
Minimum with Top and Bottom Plates: 5.25"
Maximum with Top and Bottom Plates: 6.0"
The top and bottom plates can be removed for larger devices.

Spine Plate Dimensions:
2.5W x 5.0H"

Using Short Arm Side Clamps:
Maximum Depth: 0.75"
Minimum Width: 1.25"
Maximum Width: 3.0"

Using Medium Arm Side Clamps:
Maximum Depth: 1.25"
Minimum Width: 1.5"
Maximum Width: 3.5"

Using Long Arm Side Clamps:
Maximum Depth: 1.6"
Minimum Width: 2.25"
Maximum Width: 3.5"

Included with Purchase:
(1 qty) Universal Finger Grip holder
(1 qty) Base/ball adaptor (attaches directly to cradle)
(1 qty) Standard size double socket arm
(1 qty) Mounting base (mounts to either brake/clutch reservoir or rail/handlebar)
Hardware for mounting to either brake/clutch reservoir or rail/handlebar

Material:
High Strength Composite and Powder Coated Marine Grade Aluminum

Ball Size:
1" Rubber Ball "B" Size

Note:
*The RAM-B-174-UN4U can mount to both the brake/clutch reservoir or any round rail that is 0.5" to 1.25" in diameter.The "U" in the part number reflects product packaged in poly bag. To see if the RAM-B-174-UN4U base will mount to your motorcycle, check the hole spacing of the base against your clutch/brake reservoir. The holes centers have a minimum width of 0.94" and a maximum of 1.58".

The RAM Mounting Systems RAM-B-174-UN4U Universal Finger Grip Holder offers a versatile solution for securely mounting cell phones, GPS devices, and two-way radios on motorcycles, ATVs, or similar vehicles. Constructed from high-strength composite and marine-grade aluminum, this holder is designed to withstand harsh environments while providing a reliable grip on your device. The base features a 1-inch diameter rubber ball that allows for multiple pivot points via rubber ball and socket technology, enabling almost infinite adjustment for optimal viewing angles and accessibility. The mounting hardware accommodates reservoirs and rails ranging from 0.5 inches to 1.25 inches in diameter, with standard and metric bolt compatibility ensuring compatibility with a wide variety of vehicles. The included hardware and mounting base facilitate quick installation on brake or clutch reservoirs or round rails, making it suitable for many applications. The holder itself employs three sets of four flexible rubber-coated fingers that securely grip devices of various sizes. The fingers open by squeezing the ends, allowing easy insertion and removal of your device, while the back plate provides additional support. The holder's height adjusts from approximately 5.25 inches to 6 inches when the top and bottom plates are in place, and these plates can be removed for larger devices. The spine plate measures 2.5 inches wide by 5 inches high, supporting a wide range of device sizes. The side clamps come in short, medium, and long arm configurations, accommodating device depths up to 1.6 inches and widths up to 3.5 inches. This flexibility ensures a snug, secure fit for a variety of electronic devices. Included with your purchase are the universal finger grip holder, a base/ball adapter, a standard double socket arm, and the mounting base with hardware, ready for installation on your vehicle. Designed for durability and ease of use, the RAM-B-174-UN4U is an excellent choice for riders and outdoor enthusiasts seeking a reliable device mounting solution that adapts to their needs and environment.

Features:

• Universal mounting base compatible with brake and clutch reservoirs or round rails 0.5" to 1.25" in diameter

• Adjustable multi-pivot design with rubber ball and socket technology for optimal viewing angles

• Constructed from high-strength composite and marine-grade aluminum for durability

• Flexible rubber-coated fingers securely grip a wide range of devices, including cell phones, GPS units, and radios

• Height adjustable from approximately 5.25" to 6" with removable top and bottom plates for larger devices

• Side clamp options include short, medium, and long arms to accommodate various device sizes and depths

• Quick-release mounting hardware for easy installation and removal

• Includes universal finger grip holder, base/ball adapter, double socket arm, and mounting base
