Seatronx SRT-27 27-Inch Sunlight Readable Touch Screen Display for Marine and Industrial Applications

27" Wide Screen Sunlight Readable Touch Screen Display

Seatronx multi-input rugged displays are not only durable but are perfect for today's sleek glass bridge helms in sizes from 12 to 27.

The SRT display pairs with GARMIN giving you the ultimate black box navigation solution using Garmins fully integrated GPSMAP 8700 processor and Seatronx SRT series displays.

Features:

• Mounting - Panel Mount , Vesa Mount


• Dimensions - 26.01" x 16.46" x 2.40"


• Cutout Dimensions - 25.3" x 15.75" x 2.40"


• Projected Capacitive Touch


• Optical Bonding


• Optional Remote Control

Technical Specifications:

• Diagonal (active area) Inch - 27"


• Native Resolution (Pixels) - 1920x1080


• Contrast Ratio - 1000:1


• Brightness - 1000


• Viewing Angle (left, right) - 89, 89


• Viewing Angle (up, down) - 89, 89


• Backlight Dimming - 0 - max


• Backlight Lifetime (Hrs) - 50,000


• Input terminal x1 HDCP HDMI - HDMI, DVI, VGA, Comp


• Power Source - 9-34V + and -


• Power Consumption (AMPS @ 24VDC) - 3.5


• Inlet Plug DC Power - Screw Terminal


• Sealing Front - IP68 with Potentiometer


• Operating Temperature (C) - 0 to 50


• Storage Temperature (C) - -20 to 60

The Seatronx SRT-27 is a rugged 27-inch wide screen display designed for demanding environments such as marine navigation and industrial control panels. Featuring a sunlight-readable display with a brightness of 1000 nits, it ensures clear visibility even in direct sunlight. Its projected capacitive touchscreen with optical bonding provides precise touch response and durability, making it suitable for touch-intensive operations. The display supports multiple input terminals including HDMI, DVI, VGA, and composite, providing versatile connectivity options for various devices and systems.

Constructed with an IP68 sealed front, the SRT-27 is built to withstand harsh conditions, including water and dust ingress, while maintaining reliable performance. The display's backlight lifetime exceeds 50,000 hours, ensuring long-term operation with minimal maintenance. It is designed for easy mounting, offering both panel mount and VESA mount options, and includes a convenient screw terminal for DC power connections. The display's wide viewing angles of 89 degrees in all directions facilitate multiple viewers and collaborative environments.

The integrated design pairs seamlessly with Garmin's GPSMAP 8700 processor, providing an all-in-one navigation solution. Its robust construction, high contrast ratio of 1000:1, and excellent color reproduction make it ideal for critical applications where visibility and durability are paramount. Operating within a temperature range of 0 to 50°C, the SRT-27 ensures reliable operation across diverse climates. For detailed installation and operation instructions, consult the owner’s manual available online.

Features:

• Mounting options include panel mount and VESA mount for flexible installation

• High brightness of 1000 nits ensures sunlight readability

• Projected capacitive touch with optical bonding provides durability and precise responsiveness

• Supports multiple input terminals: HDMI, DVI, VGA, and composite

• Sealed front with IP68 rating offers water and dust resistance

• Long backlight lifetime of 50,000 hours for reliable long-term use

• Wide viewing angles of 89 degrees in all directions for collaborative viewing

• Easy power connection via screw terminal with 9-34V power range

• Compatible with Garmin GPSMAP 8700 series for integrated navigation
