Description
Lithium Battery 24VDC 300Ah NG Smart LifePO4
The NG (Next Generation) series builds on the achievements of the Lithium Smart Series, featuring substantial improvements. Designed for individuals in need of sophisticated and dependable energy storage solutions, the Lithium NG series represents a crucial development in our product range, prepared to address the challenges of the future.
Victron Energy Lithium NG batteries are Lithium Iron Phosphate (LiFePO4 or LFP) batteries available with nominal voltages of 12.8V, 25.6V, and 51.2V in various capacities. They can be connected in series, parallel, and series/parallel so that a battery bank can be built for system voltages of 12V, 24V, or 48V. The maximum number of batteries in one system is 50, which results in a maximum energy storage of 192 kWh in a 12V system and up to 384 kWh in a 24V and 48V system.
Integrated shunt
The battery data (battery voltage, current, and temperature) are transmitted to the BMS and evaluated there, i.e. to calculate the state of charge, which can then be read out via VictronConnect or a GX communication center, or to create and issue specific warnings and alarms.
Automatic setup, monitoring, and control via VictronConnect App or a GX device and the VRM Portal
All battery parameters are managed by the BMS automatically. The BMS automatically detects the system voltage and the number of batteries in parallel, series, and series/parallel connections. The BMS (from now on Lynx Smart BMS NG 500 A/1000 A, further models to follow) is mandatory and must be purchased separately.
Monitoring and control take place via VictronConnect (every BMS model has Bluetooth), a GX communication center, or the VRM Portal. You can view battery parameters such as cell status, cell voltages, battery current, and temperatures in real time. The battery firmware is automatically updated by the BMS.
Easy bracket mounting
Mounting brackets make the installation easier and ensure that the battery is optimally secured against slipping and tipping over.
Increased ingress protection (IP-rating)
The Lithium NG batteries are effectively sealed against dust and can withstand low-pressure water jets, making them suitable for environments where exposure to dust and water is a concern.
Low self-discharge rate
The self-discharge rate has been significantly improved and is now a maximum of 2 % of the battery capacity per month. A low self-discharge rate contributes to the overall performance, longevity, and reliability of the NG batteries.
Features:
- Multiple improvements including added read-out of cell voltages and temperatures
- Maximum single bank size increased to 385kWh
- Modules available in 12, 24 and 48V
- Protection class IP65
- Bracket mounting and strap mounting
The Victron Energy Lithium Battery 24VDC 300Ah NG Smart LifePO4 is a cutting-edge energy storage device designed for demanding applications requiring high capacity and dependable performance. Built with advanced Lithium Iron Phosphate (LiFePO4) chemistry, this battery delivers long-lasting, stable power suitable for a wide range of systems. Its modular design allows for flexible configuration in series and parallel connections, enabling system voltages of 12V, 24V, or 48V with a maximum capacity of up to 385 kWh in a single bank. This makes it ideal for large-scale renewable energy projects, off-grid solutions, and industrial applications.
The NG series introduces several enhancements over previous models, including an integrated shunt for real-time system monitoring and a Bluetooth-enabled BMS for seamless control via the VictronConnect app or GX communication center. The BMS automatically detects the system configuration, manages all parameters, and provides detailed data such as cell voltages, temperatures, and current. Firmware updates are handled automatically, ensuring the battery remains up-to-date with the latest features and security improvements. An optional Lynx Smart BMS NG is required for full system integration and advanced management, sold separately.
Designed for durability and ease of installation, the Lithium NG batteries feature easy-to-mount brackets and are sealed to meet IP65 standards, providing protection against dust and low-pressure water jets. Their low self-discharge rate of just 2% per month enhances long-term reliability, making them suitable for both stationary and mobile applications. The batteries are also equipped with safety features and are constructed to withstand environmental challenges, ensuring optimal performance in various conditions. Overall, the Victron Energy Lithium Battery 24VDC 300Ah NG Smart LifePO4 offers a sophisticated, scalable solution for energy storage needs, combining advanced monitoring, safety, and ease of use for professional and DIY installers alike.
Features:
- Multiple improvements including added read-out of cell voltages and temperatures
- Maximum single bank size increased to 385kWh
- Modules available in 12V, 24V, and 48V configurations
- Protection class IP65 for dust and water resistance
- Easy mounting with brackets and straps for secure installation
- Integrated shunt for real-time system monitoring
- Bluetooth connectivity for monitoring via VictronConnect app
- Automatic detection of system voltage and configuration
- Low self-discharge rate of 2% per month for longevity
- Scalable system design supports up to 50 batteries
