Description
Skylla - 24/100 TG Charger - 230V
One full rated output and one (1) 4 Amp output. Charge voltage can be precisely adjusted to suit any battery system.
The input for the charger is 230V at 50/60HZ. Charge voltage can be measured directly on the battery terminals in order to compensate for voltage loss due to cable resistance.
An external sensor allows to measure battery temperature and compensate charge voltage accordingly.
Features:
- Perfect chargers for any type of battery - Charge voltage can be precisely adjusted to suit any sealed or unsealed battery system. In particular, sealed maintenance-free batteries must be charged correctly in order to ensure long service life. Overvoltage will result in excessive gassing and venting of a sealed battery. The battery will dry out and fail.
- Suitable for AC and DC supply (AC-DC and DC-DC operation)
- Every TG Charger has a microprocessor, which accurately controls the charging in three steps
- Use of TG Chargers as power supply - As a result of the perfectly stabilized output voltage, a TG Charger can be used as a power supply if batteries or large buffer capacitors are not available.
- Manufactured with a battery temperature sensor. When connected, charge voltage will automatically decrease with increasing battery temperature.
- In order to compensate for voltage loss due to cable resistance, TG Chargers are provided with a voltage sensor so that the battery always receives the correct charge voltage
Technical Specifications:
- Input Voltage - 230V AC
- Input Voltage Range - 185 to 264V AC
- Input Voltage Range - 180 to 400V DC
- Battery Capacity - 500 to 1000 Ah
- Frequency - 45 to 65 Hz
- Battery Connection - M8 studs
- 230V AC Connection - Screw clamp (AWG 6)
- Dimensions (H x W x D) - 14.4" x 9.9" 10.1" (36.5 x 25 x 25.7 cm)
- Weight - 22 Lbs (10 kg)
In the Box:
- Charger
- Mounting brackets
- Temperature sensor with 4.9' (1.5 M) wire
- Instruction manual
*Sold as an Individual
Please contact your dealer for any returns, repairs or support issues related to this product.The Victron Energy Skylla 24/100 TG Charger is a versatile and reliable power solution designed for charging large battery systems in marine, industrial, and renewable energy applications. With a fully adjustable charge voltage and a robust microprocessor-controlled three-step charging process, this charger ensures optimal battery health and longevity. Its design accommodates batteries from 500 to 1000 Ah, making it suitable for demanding power needs. The charger operates on a 230V AC input with a wide voltage range, providing consistent performance even under fluctuating supply conditions.
The Skylla 24/100 TG features a 24V output with a rated current of 100 Amps, complemented by an additional 4 Amp output for auxiliary charging needs. It includes a battery temperature sensor that automatically adjusts the charge voltage based on temperature variations, preventing overcharging and extending battery life. The device also measures and compensates for voltage drops caused by cable resistance through an integrated voltage sensor, ensuring the battery receives the correct charge voltage at all times. Its compatibility with both AC and DC power sources allows for flexible installation and operation in diverse environments.
Constructed with durable materials and equipped with M8 battery connection studs, the Skylla 24/100 TG offers reliable performance and ease of installation. The charger can be used as a power supply in situations where batteries or large buffer capacitors are unavailable, thanks to its stabilized output voltage. Its compact dimensions and included mounting brackets facilitate straightforward integration into existing systems. The package includes the charger, mounting brackets, a temperature sensor with a 4.9-foot wire, and an instruction manual for setup and maintenance.
Designed for professional use, this charger is an essential component for ensuring the safety and efficiency of large battery systems. Proper charging is critical for maintenance-free batteries, especially sealed types, as overvoltage can cause excessive gassing and damage. For support or warranty inquiries, contact your dealer. The Victron Skylla 24/100 TG is a dependable choice for high-capacity battery management in demanding applications.
Features:
- Adjustable charge voltage to suit various sealed and unsealed battery systems
- Compatible with AC and DC power sources, supporting AC-DC and DC-DC operation
- Microprocessor-controlled three-step charging process for optimal battery health
- Can be used as a power supply due to stabilized output voltage
- Includes a battery temperature sensor for automatic voltage compensation
- Voltage measurement and compensation for cable resistance to ensure correct charging voltage
