Garmin ECHOMAP UHD2 93SV LiveScope Plus Ice Fishing Bundle LI with 9-Inch Combo and Lithium Battery

ECHOMAP UHD2 93SV LiveScope Plus Ice Fishing Bundle LI with ECHOMAP UHD2 93sv, LiveScope Plus System Lithium-ion Battery

Get improved resolution, reduced noise, clearer images, and better target separation with the LiveScope Plus Ice Fishing Bundle LI. It includes a 9-inch ECHOMAP UHD2 combo, the complete LiveScope Plus System with LVS34-IF transducer, swivel pole mount, and a lightweight lithium battery.

Features:

• Get improved clarity, sensitivity, and Target Separation


• Scan surroundings with reduced noise and fewer sonar artifacts


• Use LiveScope forward mode so you know where to drill


• Use LiveScope down mode so you can keep an eye on your jig and the fish


• Fish longer with a 16.5AH lightweight lithium-ion battery


• Includes a rugged, portable carrying case


• LiveScope Forward sonar shows up to 200 all around you and below the ice, so you can locate schools of fish and know where to drill the next hole


• LiveScope Down sonar shows live sonar images of what is below the ice, so you can watch fish respond to your jig


• Where you take your bundle is up to you. But the rugged, portable carrying case lets you easily transport it from hole to hole and season to season

ECHOMAP UHD2 Combo

Revolutionary real-time sonar pairs with a large 9-inch ECHOMAP UHD2 combo touchscreen display with a keyed assist, allowing you to see up to 200 in any direction.

Two Modes One Transducer

LiveScope System offers two live-scanning sonar modes Down and Forward. It features a transducer cable that stays flexible, even in freezing conditions

Garmin Navionics+ Maps

You get preloaded Garmin Navionics+ maps for exceptional detail on more than 23,000 U.S. lakes.

Custom Combos

You can create custom pages that combine sonar, flashers, and maps on your display.

Lithium Battery

Fish even longer with a lightweight 16.5Ah lithium battery that wont weigh you down on the ice.

In the Box:

• ECHOMAP UHD2 chartplotter (version depends on mapping selected)


• LVS34-IF transducer


• GLS 10 sonar module


• Ice fishing pole mount


• Tilt mount


• Power cable


• Portable fishing bag with a handle


• Lithium-ion battery


• Battery charger


• Documentation

General Specifications:

• Dimensions: 13.8 x 12.2 x 13.0 in. / 35 x 31 x 33 cm


• Touchscreen: Yes


• Input: Touchscreen with Keyed Assist


• Display Size: 7.8 x 4.5, 9.0 in. / 19.8 x 11.5, 22.9 cm


• Display Resolution: 1024 x 600 pixels


• Display Type: WVGA, IPS


• Weight: 22.5 lbs / 10.2 kg


• Waterproof: IPX7

Maps Memory:

• Accepts Data Cards: 1 microSD card; 32 GB maximum size


• Waypoints: 5000


• Track Points: 50,000


• Tracks: 50 saved tracks


• Navigation Routes: 100

Ice Fishing Details:

• Battery Type, Size: Lithium-ion, 16.5Ah


• Bag Size: Extra Large (XL)


• Included Transducer: LiveScope Plus System with LVS34-IF


• Transducer Holding Feature: Pole mount

Sensors:

• Has Built-in Receiver: Yes


• Receiver: 10 Hz


• NMEA 2000 Compatible: Yes


• GPS: Yes


• Glonass: Yes


• Galileo: Yes


• Beidou: Yes


• Supports Waas: Yes


• Supports Multi-Band, Multi-Constellation GPS: Yes

Built-in Maps:

• Built-in Auto Guidance+: Yes (downloadable via ActiveCaptain app)


• Garmin Navionics+ Inland Coastal: Yes (see Additional)


• Garmin Navionics+ (Inland): Yes (see Additional)

Optional Map Support:

• Garmin Navionics+: Yes


• Garmin Navionics+ VIision+: Yes


• TOPO: Yes


• Standard Mapping: Yes


• Garmin Quickdraw Contours: Yes

Chartplotter Features:

• ActiveCaptain Compatible: Yes

Electrical Features:

• Power Input: 9 to 18 Vdc

Sonar Features Specifications:

• Displays Sonar: Yes


• Power Output: 500 W


• Traditional Sonar (Dual Frequency/Beam): Built-in (single channel CHIRP, 50/77/83/200 kHz, L, M, H CHIRP)


• ClearV: Built-in 260/455/800/1000/1200 kHz


• SideV: Built-in 260/455/800/1000/1200 kHz


• Panoptix Sonar: Yes


• Livescope; Yes

Connections:

• NMEA 2000 Ports: Yes


• Garmin Marine Network Ports: 1


• 12-Pin Transducer Ports: 1


• Bluetooth Pairing: Yes


• Ant+ (Connectivity): Yes


• Garmin Wi-Fi Network (Local Connection): Yes

Additional:

• Garmin Navionics+ Inland Coastal: 95sv Canada


• Garmin Navionics + (Inland): 95sv U.S. Lakes

WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov.

The Garmin ECHOMAP UHD2 93SV LiveScope Plus Ice Fishing Bundle LI is designed to enhance your ice fishing experience with superior imaging and real-time scanning capabilities. This comprehensive package includes a 9-inch ECHOMAP UHD2 combo touchscreen display with keyed assist, offering crystal-clear visuals and responsive control. The system features advanced sonar technology, providing improved resolution, sensitivity, and target separation to help you locate fish more efficiently beneath the ice. The LiveScope Plus System with LVS34-IF transducer enables forward and downward scanning modes, giving you a 200-degree panoramic view and live images of fish below, so you can precisely determine where to drill and keep an eye on your jig and fish activity.

Durability and portability are key in ice fishing conditions, which is why Garmin includes a rugged, portable carrying case and a lightweight 16.5Ah lithium-ion battery that extends your fishing sessions without adding unnecessary weight. The bundle also features Garmin Navionics+ maps for detailed lake information across over 23,000 U.S. lakes, and allows you to create custom pages that combine sonar, maps, and other data for a tailored fishing experience. The system's multi-constellation GPS and GLONASS support ensure accurate positioning even in challenging environments, while compatibility with ActiveCaptain and Wi-Fi facilitates easy updates and connectivity.

This system integrates seamlessly with your existing marine electronics network through NMEA 2000 and Garmin Marine Network ports, supporting multiple data sources and sharing information across devices. The included LVS34-IF transducer is flexible for use in freezing conditions, and the package contains all necessary accessories, including mounting hardware, power cables, and documentation. Whether you are a seasoned angler or an avid ice fisher, the Garmin ECHOMAP UHD2 93SV LiveScope Plus Ice Fishing Bundle LI offers advanced imaging, reliable navigation, and portability to maximize your time on the ice and improve your catch rate.

Features:

• Improved clarity, sensitivity, and target separation for precise fish detection

• Reduced noise and fewer sonar artifacts for clearer images

• LiveScope forward mode to identify optimal drilling locations

• LiveScope down mode to monitor jig and fish activity below

• Includes a lightweight 16.5Ah lithium-ion battery for extended fishing sessions

• Rugged, portable carrying case for easy transport and storage

• LiveScope Forward sonar provides up to 200 degrees around you and below the ice

• LiveScope Down sonar offers real-time images of underwater activity

• Revolutionary 9-inch touchscreen combo display with Keyed Assist

• Preloaded Garmin Navionics+ maps for detailed lake navigation

• Create custom display pages combining sonar, maps, and more

• Supports multi-constellation GPS with GLONASS, Galileo, Beidou, and WAAS

• Compatible with Auto Guidance+ and additional map options

• Powerful 500W sonar with dual-frequency CHIRP and ClearV/SideV technology

• Multiple connectivity options including NMEA 2000, Wi-Fi, Bluetooth, and Ant+
