HEISE LED Lighting Systems Dual Row Marine LED Light Bar - 8 inch

Dual Row Marine LED Light Bar - 8"

SPECS

• Input Voltage: 10-30V DC


• Wattage: 36W (12-3WCREELEDs)


• Raw Lumens: 2880


• Color Temperature: 6000K


• Beam Pattern: Combo/Flood(90deg)/Spot(8deg)

CONSTRUCTION

• Housing Material: Die-cast Aluminum Housing


• Housing Color: White Coating with UV Inhibitors


• Membrane: Gore


• Lens Material: PC


• Mounting Bracket: Die-cast Aluminum


• Hole Dimensions: Brackets turned inward 7.25in


• Brackets turned outward 9.5in


• Mounting Bolt Drill .25in


• Electronics: Integrated-Epoxy Encapsulated


• Hardware: Stainless 316

OPERATION

• Operating Temperature: -40degC to +60degC


• Current Consumption: 1.9 amps at 13.8 volts


• IP Rating: IP68


• Protections: Reverse Polarity

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The HEISE LED Lighting Systems HE-MDR8 is an 8-inch dual row marine LED light bar designed for optimal illumination and durability in marine environments. This light bar features a die-cast aluminum housing with a UV-inhibiting white coating, ensuring robust protection against harsh weather conditions and prolonged exposure to sunlight. The lens is made of impact-resistant polycarbonate, providing clear and reliable light output. Integrated epoxy encapsulation on the electronics offers enhanced water resistance, making this light bar suitable for demanding marine applications. The stainless steel hardware and mounting brackets add to the overall durability, enabling secure installation on boats and other marine vehicles. With a power consumption of just 36 watts, it delivers a raw lumen output of 2880 lumens, offering bright and efficient illumination. The light bar provides multiple beam patterns—combo, flood, and spot—allowing you to customize your lighting setup for various tasks and conditions. Operating over a wide voltage range of 10-30V DC, it is compatible with most marine electrical systems and includes reverse polarity protection for added safety. Its compact design incorporates adjustable mounting brackets, with hole dimensions accommodating 0.25-inch bolts, enabling flexible installation options. The IP68 rating ensures the light is completely dust-tight and protected against water immersion, making it an ideal choice for demanding marine environments. Please note that this product contains chemicals known to cause reproductive harm according to California's Proposition 65, and appropriate precautions should be taken during installation and use.

Features:

• Input Voltage: 10-30V DC for versatile marine application compatibility

• Wattage: 36W with 12 Cree LEDs for bright illumination

• Raw Lumens: 2880 for powerful light output

• Color Temperature: 6000K providing bright white light

• Beam Pattern: Combo, flood (90°), and spot (8°) for customizable lighting

• Housing Material: Die-cast aluminum with UV inhibitors for durability

• Lens Material: Impact-resistant polycarbonate for clarity and toughness

• Mounting Hardware: Stainless steel 316 for corrosion resistance

• Operating Temperature: -40°C to +60°C ensures reliable performance in various conditions

• Waterproof Rating: IP68 for complete dust and water immersion protection

• Reverse Polarity Protection to safeguard electronics against incorrect wiring
