Hella Marine Surface Mount Oblong LED Courtesy Lamp with White LED and Stainless Steel Bezel

Surface Mount Oblong LED Courtesy Lamp - White LED - Stainless Steel Bezel

Oblong LED lamps are offered as either dedicated step lamps or general courtesy illumination with equal vertical spread.

Step lamps carry engineered optics to direct light downwards at 30 safely illuminating deck and step tread surfaces without shining into the eyes.

Completely sealed and ultra durable, Hella Marine LED lamps may be installed on a vessels interior or exterior, wet or dry.

Polished 316 Stainless Steel bezels are included with each part number. Black and white plastic end caps are also included.

Specifications:

• Lens Material: UV and enhanced impact resistant Grilamid


• Rim Material: 316 stainless steel


• Cable: Pre-wired with 120mm of marine cable


• Operating Voltage: Multivolt 12 / 24V DC


• Power Consumption: 0.5W ( < 0.04A@12V / < 0.02A@24V )


• Degree of Protection: IP 67 - Completely Sealed


• Mounting: Stainless steel screws included


• Weight: 35g (including cable)


• Approvals: CE

The Hella Marine Surface Mount Oblong LED Courtesy Lamp is designed for versatile interior and exterior vessel lighting applications. Featuring a durable stainless steel bezel and UV-resistant, impact-enhanced Grilamid lens, this lamp offers reliable performance in marine environments. Its compact, oblong shape provides an even vertical light spread, making it suitable as either a dedicated step lamp with downward-engineered optics or general courtesy illumination. The lamp is completely sealed with an IP67 rating, ensuring protection against water ingress and harsh weather conditions, making it ideal for wet or dry environments onboard your vessel. It is pre-wired with 120mm of marine cable and includes stainless steel mounting screws for easy installation. The low power consumption of 0.5W at 12V DC or 24V DC ensures energy efficiency without sacrificing brightness. Certified with CE approval, this LED courtesy lamp combines durability, efficiency, and effective illumination in a sleek, stainless steel design that complements any marine setting.

Features:

• Durable stainless steel bezel with polished finish for marine environments

• UV and impact resistant Grilamid lens for long-lasting performance

• Pre-wired with 120mm marine-grade cable for easy installation

• Multivolt operation: 12V and 24V DC compatible

• Low power consumption at 0.5W, ideal for energy-efficient lighting

• IP67 waterproof rating, suitable for wet and dry conditions

• Includes stainless steel mounting screws for secure installation

• Compact oblong design provides even light distribution

• CE certified for safety and quality compliance
